High Brightness LED Solar Street Light 120W (JS-A20156130)
1.LED Solar Street LightsProduct Details
Basic Info.
Model NO.:JS-A20156130
Light Source:LED Lamp
Lamp Body Material:Aluminum Alloy
Light Type:Solar
Color Temperature:Cool White
Power:30w
Illumination Time:6h
Cell Type:Lithium Battery
Charging Time (H):6h
Usage:Garden, Street, Road /Outside
IP Rating:IP65
Certification:CE, RoHS
Voltage:12/24V
With Light Source:With Light Source
Warranty:5 Years
Export Markets:Global
2.Product Description
| Detailed Specification for 6M pole 30W 12V solar street light |
Part Name and Lifespan |
Technical Specification |
Solar Panel:
Lifespan:20-25 years |
120W*1PC Polycrystalline. High Efficiency. A-class
Adding Aluminum Frame, Tempered Glass. |
Gelled Battery
Lifespan:5-8 years |
120Ah/12V*1PC, Gelled battery, Sealed Type.
Deep cycle. Maintenance Free |
Intelligent Solar Controller
Lifespan:5-10 years |
15A/12V,IP65. Automatic Light and Time Control
Over-charging/discharging Protection
Reverse-connection Protection
Switch on Automatically with Light Sensor |
Light source: High Power LED
Lifespan: More than 50000-100000Hrs |
30W LED, White Color,3600LM/PC,6500K,IP65,
High Power, High Brightness. |
Lamp Housing:
Lifespan: More than 20 years |
Die-casted Aluminum, IP65
High transmittance & Density toughened glass, |
Battery Box: |
Engineer plastic,underground of the pole. |
GI Pole System:
Lifespan: More than 20 years
|
6M Height, tapered Pole, Steel,
Hot-Dip Galvanized. Plastic Coated, Rust Proof,
With Arm, Bracket, Flange, Fittings, Cable, Etc
Resistant to Wind: ≥150KM/H
|
Working Principle:
1. Solar LED street light relies on solar energy, which is clean, endless and environment-friendly.
2. The system is mainly composed of solar panel, light source, controller and free-maintenance battery.
3. In daytime, when there is sunshine, the solar panel can convert the solar energy to electric energy and store it in the battery. At night or rainy or cloud condition, the battery shall supply power for normal lighting.
4. The controller can judge the brightness of daylight and automatically switch on the light. The whole process is operating in completely automatic mode, without human action.
3.Specification:
1.solar panel: High efficiency mono or poly crystalline silicon;
2. light source: High bright LED, white, lifespan more than 50000hours;
3. controller: Intelligent microcomputer controller, 12V/24V auto, time control & light control, with over-charging and discharging protections etc;
4. battery: Gelled valve-regulated sealed battery, maintenance free and deep cycle;
5. light pole: 5-10 meters pole, made of quality steel, plastic coated after hot dipped galvanized, rust proof. Wind resistance ≥ 120km/h;
6. work temperature: Ambient temperature for -30--+60 degree c;
7. lighting time: Usually 8 /10/12 hours lighting per night, 3-4 / 5-6 rainy or cloudy days;
8) voltage: Advisable DC24V for LED above 40W.
4.Our Service
1, Reply your inquiry in 24Hrs.
2, Feedback of complaint in 24Hrs.
3, Exclusive agents in local country are welcomed.
4, High quality control with CE, ROHS approval.
5, Manufacturer specialize in led street lighting and controller.
6, 10000 kits every month to guarantee the best delivery time.
7, Powerful R&D ability---All products belong to our private mold and own design.
8, Three or five years warranty policy, up to now, our product defective rate is under 0.5%.
5.JINGSHANG Brief
Since founded in 2009, JINSHANG is growing very fast with annual growth of 40%, in 2011 we have become one of the largest solar street lighting companies in China. Our customers are from more than 30 countries in the world, and more and more find us and request to start a cooperation.
We hold the management principle of "strive for survival on the basis of quality, explore the markets on the basis of sincerity". The developing goal is to meet the requirements of our clients and to establish the brand effect of Jinshang. We implement the special technical activities and establish qualified archives in a long time, which is to improve and enhance our manufacturing technique. We also try our best to make our rules and regulations perfect. We will continue to warmly welcome the communities to come to new and old customers visit our company and guide!
Installation
