1, Item No.: Single Sided LED Light Box
(1)A1(594mm wide, 841mm height) size illuminated poster frame single side lightbox with strut and printed posters.
(2)Power cable(3m) at the bottom of the frame.
(3)Cables and sleeves(800mm) on top
2, Frame: Aluminum Alloy (Four Clip Type)
3, Color: Electrophoresis Silver
4, Thickness: 14mm, Frame Width: 40mm
5, Light Source: LED
6, Slim Type, Easy to Install
7, Application: Airport, bus-stop, metro-station, chain store, shopping mall, supermarket, hotel, restaurant, bank, exhibition and so on.
1. Material: Aluminium alloy profile, acrylic sheet for light guide panel, PVC bottom panel.
2. Light Source: High quality SMD, supply AC/DC adaptor, with the plug suit to different countries, input: 100 to 240V AC 50/60Hz, working on 12VDC.
3. Life Span of LED: Above 50, 000 hours,
4. Size: Any customized is ok(over 300mm, less than 3000mm)
Standard size as follow in the chart:
5: Application: Using in door, widely use in lift, hotel, restaurant, supermarket, mall, bakery, airport, station, stores etc.
6. Advantage: Energy saving, environment friendly, easy to change the poster and install.
7. Warranty: 1 year.
Model | Frame Size
( mm ) | Picture Size
(mm) | Visible Size
( mm ) | Thickness | Weight
(KG) | Power |
| A0 | 1249*901 | 1204*856 | 1189*841 |
Thickness15MM
Cover Width 30MM | 15 |
|
| A1 | 901*654 | 856*614 | 841*594 | 8 |
|
| A2 | 654*480 | 614*440 | 594*420 | 6.8 |
|
| A3 | 480*357 | 440*317 | 420*297 | 2.8 |
|
| A4 | 357*270 | 317*230 | 297*210 | 2.1 |
|
