Home LED Light Products Good Quality Indoor P7.62 Aluminium Die-Casting Rental/Moving LED Screen/LED Display

Good Quality Indoor P7.62 Aluminium Die-Casting Rental/Moving LED Screen/LED Display

Good Quality Indoor P7.62 Aluminium Die-Casting Rental/Moving LED Screen/LED Display
Price: US $ 430-480/Square Meter
Trade Terms: FOB,CIF,EXW
Min Order: 1/Square Meter
Pay Type: L/C,T/T,Western Union
P7.62 SMD Full Color Die-casting Aluminnum Indoor Video Screen
Specifications
1. No noise, quiet when operation.
2. Black LED with high contrast
3. Die-casting aluminum, good heat dissipation
4. CE ,CCC,FCC,UL,RoHS


Our company is a LED Screen manufacturing with a 11 million of registered capital and over 300 employees in Shenzhen.
We have the most populous led industrial area, with a cover of more than 10,000m2 and cover 300 million of amount of sales per year.
And spans a wide range of products covering:Indoor/Outdoor Full Color  LED Display ,LED Television Displays etc.We has been promoting
itself by advanced technology and scientific managements and has the following certifications:ISO9001:2008 Qulaity Systerm Certification,
ISO1400:2004 Environment System Certification ,CCC,CE,FCC,RoHS etc

Features & Technology Specification:
1. Widely application field and short ROI time. Commercial advertising LED display screen, Stadium perimeter LED display screen, mobile trailer LED display, LED screen for mobile media, shopping mall LED display, screen for logo showing, LED display for bank or stock exchange rate showing, LED moving sign for train and bus station, LED display screen for air port, elecommunication LED display screen for information showing and instruction and ect.
2. Clear Vivid image quality displaying. Even in direct and full-on sunlight day to ensure you attract more audience to get short ROI of your LED display screen's investment.
3. Long term brightness. More than 6000 nits brightness for outdoor full color LED display, more than 800 nits brightness for indoor full color LED display capacity throught products lifetime of LED display screen.
4. Easy installation and programming. Easy and simple installation interface, use friendly software to ensure the user programme the LED display screen system.
5. Convenient servicing. Front and rear cabinet access makes maintenance work very convenient and low cost to help you concentrate more time and energy on your main marketing promotion business.
6. The list of availabe models of our LED display/screen/panels/signs. P4mm, P5mm, P6mm, P7.62mm, P10mm,P16mm and ect.



 Technical Prameters
PROJECTP7.62 indoor LED video wall for stages
Pixel pitch7.62mm
Pixel density17222Pixels/sqm
Module size(W*H)244 W(mm)122 H(mm)
Module pixels(W*H)32Pixels(W)16Pixels(H)
Pixel configuration1Red 1Green 1Blue
Drive modeconstant current driving 1/8 scan
LED lamp typeSMD3528
Cabinet size(W*H*D)732 W(mm)732 H(mm)
Cabinet resolution96Pixels(W)96Pixels(H)
Color scale65,536 degree
View angle(H/V)140/120 degree
Brightness (White balance)≥2500cd/sqm.
Power consumption(one cabinet)Max:650W/sqm.     Average:200W/sqm.
Operating VoltageAC100V±10% or 220V ±10%;   50---60HZ
Net weight12Kg/Cabinet
Operating temperature-20°C----+50°C (Customized power supply:-45°C---+60°C)
Operating humidity10%_95%RH
Life time≥100,000hours
MTBF5,000 hours
Whole Display Flatness≤0.1mm Juncture
Frame frequency>60 Hz/s
Refresh rate≥2000Hz /s
Control distance100m (without repeater), single mode fiber:20km, multi mode fiber: 500m
Power 110V/220V±15% 50--60Hz
LED control systemLINSN,Dbstar,Nova-star,ZDEC,Colorlight is selectable
Operating systemWindows 2000 / Windows Xp / Windows 7
Protections for outdoor display  IP31
Maintenance wayRear  Access or Front Access
Accepting signal with video processorPAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI

Prod Model: indoor p7.62
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Module Size: 244mmx244mm
Module Resolution: 32X32
Cabinet Size: 976mmx976mm
Cabinet Resolution: 128X128
Contrast: 1000:1
Tube Chip Color: Full Color
Display Function: Video Display
Pixel Pitch: 7.62mm
Pixel Configuration: 1R,1G,1B
Pixel Density: 17,200 dots / m²
Scanning Mode: 1/8 Scan
System Operating Platform: WIN XP
Display Type: LED Video Display
Application: Shopping Guide
IP Rating: IP43
Certification: FCC
Shenzhen Teeho Optoelectronics Co. Ltd(short for Teeho Optoelectronics), found in 2009, is a high-tech private enterprise specialized in LED Screens manufacturing with a ¥ 11 million of registered capital and over 300 employees in Shenzhen. It has been dedicating itself to offering one-stop LED display solutions to its customers including R&D, prototyping, assembly, sales and technology support across the globe.

Teeho industrial park is located in Bao'an, Shenzhen, the most populous LED industrial area, with a cover of more than 10, 000 m2 and over 300 million of amount of sales per year, fully equipped with modern automatic assembly lines with the manufacturing capabilities of 8000 m2 per month

Teeho Optoelectronics spans a wide range of products covering: Indoor Full-Color LED Displays, Out Full-Color LED Dislays, LED Television Displays etc, applied to governmental institutions, corporate image projects, business ads, media activities, cultural and entertainmental places, stadiums, stations and airports etc.

Teeho Optoelectronics is focusing all efforts to technology-leading strategies of production by relying on the three-tier talent strategy, gathering high profile professional talents, which makes a foundation of new R&D of products and specially custom-made products. The R&D teams of Teeho electronics have been dedicating themselves to one-stop solutions, and have obtained tens of certifications of products and innovative patents. Moreover, they have outstandingly achieved in high-end indoor full color display solutions.

Teeho electronics has been promoting itself by advanced technology and scientific managements and has the following certifications: ISO9001: 2008 Quality System Certification, ISO1400: 2004 Environment System Certification, CCC, CE, FCC, RoHS etc. With high quality and perfect service, Teeho Optoelectronics has built lots of sales and service networks and its high-quality products has been exported into more than 80 countries and areas such as the United States, India, New Zealand. Japan, Thailand, Taiwan and Hongkong.

Teeho Optoelectronics Co., Ltd has been marching on under core values of Integrity, Pragmatic, Harmony, Creativity to guide our staff members and to devote itself to leading status in this industry, to ensure that our client will be fulfilled with the high-quality products and best service. With the horizontal developments in industrial chain and a variety of for-profit models, we vigorously promote the construction of brand culture, strive to become a world-class brand researched and developed independently, to become the most professional LED screens and one-stop solutions supplier, which makes a contribution to competing of national brands in globe markets.
