Led light manufacturers and factory

Home LED Light Products Full Color P5 SMD Large Billboard LED Outdoor Displays

Full Color P5 SMD Large Billboard LED Outdoor Displays

Full Color P5 SMD Large Billboard LED Outdoor Displays
Price: US $ 1270-1350/Square Meter
Trade Terms: FOB,EXW
Min Order: 1/Square Meter
Pay Type: T/T,Western Union
Full Color P5 SMD Large Billboard LED Outdoor Display

Features:
1. High brightness. Use DIP LEDs, keeps the display content visible even if facing the strong sunshine directly.
2. With Anti-UV ray mask, the color of the mask would never change even if under exposure of UV ray.
3. Waterproof design, completely outdoor use.
4. Easy for assembling and connection with the connector added.
5. High color uniformity and clear image can bring you a vivid audio visual effect.
6. Both front and rear access are available.
7. Good LED Chips, with large viewing angle, lowe power consumption and good color uniformity.
8. Easy for maintenance.
9. Good quality raw material, accurate technique and careful inspection insures the high quality of LED display.

Application Case:
Widely used for shopping malls, entertainment venues, schools, government agencies, trade fair, fair, aiming at the exhibition, press conference, meeting rooms, cinemas, airports, hotels, internal, station waiting area, indoorstadium, and a variety of public facilities and etc.

Our service:
1. Inquiry response time: within 24hrs.
2. OEM&ODM: design and produce your customized requirements.
3. Provide distributors customized design and models we already have.
4. Protect your sales area, design idea and all your private information.
5. Top quality + reasonable price+ patient after-sales service.
6. Mountain A-Li Group can also offer you LED stage display, LED outdoor video wall, wedding LED display, stage LED electronic screen and LED large screen full color display

Trade Terms
1. Package: Anti-shaking wooden package, Air flight case or Carton package
2. Payment: T/T, 30% deposits before production, 70% balance to be paid before delivery
3. Shipping freight are quoted under your requests
4. Shipping port: Shenzhen, Mainland China
5. Warranty time: 2 years
6. Delivery time: 3-12 working days



Unit ModuleItem parameter
Model ALS - P5 - 8S
Module size 160mm*160mm
Pixel Pitch5mm
Pixel Density40000dots/m2
Pixel Configuration 1R1G1B
Package modeSMD3528
Module Resolution 32dots(W)*32dots(H)
Max power consumption 25W
Module Thickness14.27mm(without magnet)  26.6mm (with magnet )
Module Weight 0.21kg
Driving MethodConstant Current Driving
Scan Method1/8scan
Interface WayHUB75-B
Brightness≥1600CD/M2
Unit Moduledimension 640mmx640mm
Quantity of Module16
Thermal dischargefan 2pcs
Power supply Mode 5V/40A* 2pcs
Pixel per cabinet 128mm*128mm
Thickness 85mm
Optimal Viewing Distance5M-30M
Optimal Viewing angle160°(W)120°(H)
Enviroment TemperatureStorage :-35ºC-+85ºC
work :-20ºC-+50ºC
PowerRelative Humidity10%-95%
Operating Voltage AC220V±10%
Average power consumption ≤1180W/m2         /   ≤300W/m2
Max power Consumption ≤500W/m2           /    ≤500W/m2
Current ≤20mA (Single LED )
Control systemCPUPentium4 or above P4 or above
Operate systemWIN98/2000/NT/XP
Control ModeSynchronization with PC
Main technical parameter Driving DeviceIC Constant current driving
Refresh Rate≥400HZ
Gray/ColorRGB each 256 grade, can display 16.7M clolor
MTBF≥9000hours
Power SwitchAutomatic Switch
Display Mode 800*600/1024*768



Prod Model: Full Color P5 SMD LED Outdoor Display
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Model No: Full Color P5 SMD LED Outdoor Display
Module Size: 160mm*160mm
Cabiet Size: 640mm*640mm
Brightness: ≥1600CD/M2
Best Viewing Distance: 5-30m
Best Viewing Angle: 160°(W) 120°(H)
Refresh Rate: ≥600Hz
Mean Time Between Failures: 10000 Hours
Scanning Method: 1/8 Scan
Module Thickness: 14.27cm
Tube Chip Color: Full Color
IP Rating: IP65
Pixel Configuration: 1R, 1G, 1B
Display Function: Video Display
Average Power Consumption: 600W / m²
Scanning Mode: 1/8 Scan
Display Type: LED Video Display
Application: Advertising
Certification: FCC,EMC,IP65
Pixel Pitch: 5mm
Pixel Density: 40000dots/M2
Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.
