Full color outdoor LED display, as well as single or double color outdoor LED display, Full color LED screen, Outdoor LED display, Outdoor LED display screen, advertising display etc. Are used in outdoor environment such as airport, plaza, highway, commercial walking street, residential sub-district. With various real-time signal sources and the speciality of waterproof, dustproof, staticproof, The purpose of LED display screen is to propagandize outdoor advertising or play the important news or events or TV program etc.
Technical Parameter:
P10 full color display (Real pixel)
1. LED lamp
Encapsulation Form: R: DIP 346 G: DIP 346 B: DIP 346
Brightness: R: 600mcd G: 1800mcd B: 400mcd
2. LED module
Pixel pitch: 10mm
Pixel configuration: 1R1G1B
Resolution: 16dots(W)*16dots(H)
Size: 160mm(W)*160mm(H)
3. LED Cabinet (Standard)
Resolution: 96dots(W)*96dots(H)
Size: 960mm(W)*960mm(H)
Module quantity: 6PCS(W)*6PCS(H)
Weight: 65kg
4. LED display
Pixel density: 10000dots/m2
Brightness: 7500CD/m2
Driving mode: Constant current
Scanning mode: 1/4 scan
Max power consumption: 900W
Grey grade: 16bits
Colors: 65386levels per color
Frame frequency: 60Hz
Refresh frequency: 400Hz
Brightness adjustment: 256 levels automatic
Color temperature: 6500K~9300K adjustable
Environmental temperature: Storing: -35deg~+85deg working: -30deg~+50deg
Input voltage: AC 110V/220V+-10%
Horizontal view angle: 120deg;
Vertical view angle: 60deg;
Ingress protection: Front: IP65 Rear: IP43
File format supported: TXT, JPEG, MPEG, BMP, SWF, GIF, DAT etc.
Hub type: HUB12/08/40
Best view distance: 10m
Control distance: LAN wire: 100m multi-model fiber: 500m single-model fiber: 15km
MTBF: 10, 000 hours
Life span: 100, 000 hours
