Features of our products:
Warranty:
1. We guarantee all our display, modules, spare parts (Silan Chip) for TWO years.
2. We provide technology training for free, which contains the operation and maintenance training of the LED screens in the factory.
3. After warranty, we also can offer you the parts for replacement at our bottom price.
4. After sales, if you have any problem about our product, you can inform us by Email, we will reply you at once when we get it and offer you a good solution to solve the problem.
5. We also could solve problems for you until it recovers well by remote control!
Delivery Time:
1. Delivery time: Accomplish manufacturing within 25 days after receiving the deposit.
2. Before delivery, we will test the display, and keep it light up for 72 hours, and check all the parts of the display to confirm it is OK for delivery.
Trade Terms:
1)Payment: T/T, 30% deposits before production, 70% balance to be paid before delivery
2)Shipping freight are quoted under your requests
3)Shipping port: ShenZhen, Mainland China
4)MOQ: 1pcs
|
1.1 LED Index |
|
Match colors analysis |
R:G:B=3:6:1 |
|
1.2 Technology Specifications |
|
Name |
Technology Specifications |
|
1.Physical index |
Pixel :7. 62mm |
|
Color : Red+Green+Blue |
|
Pixel configuration : 1R1G1B |
|
Pixel density :17222 dots/sqm |
|
LED type : SMD3528 |
|
2 Module |
Panel pixel(dots) : 32dots×16dots |
|
Modul size : 244mm×122mm |
|
3 Screen |
Viewing : H120 0 , V120 0 |
|
Storage temperature : -40 °C ~~ +65 °C |
|
Operated temperature : -40 °C ~~+60 °C |
|
Humidity : 10%-95% |
|
Screen thickness : cabinet thickness 12cm ( Front Maintenance ) |
|
Cabinet weight : 35kg/sqm |
|
Protection : IP31 |
|
4 Power supply |
Power : AC220V or 380V |
|
Max power consumption : 1200W/sqm average 500W/sqm |
|
5 Control system |
Computer : DELL V230 or similar computer |
|
Operating system : WIN7/2000/XP |
|
Display card : DVI |
|
Control mode : synchronization control |
|
Refresh frequency : ≥ 2000Hz |
|
Grey/Color : 16K , 4K(Optional ) /16.7M colors |
|
Calibrate Brightness : 256level adjust |
|
Control system adopts : DVI+Master card+ Internet line |
|
6 Main specifications |
Driver : Constant current |
|
Driver mode : 1/8 scan |
|
Frame frequency : ≥ 60Hz |
|
Brightness :≥ 2000cd/sqm |
|
Accepting signal : RF , S-Video , RGB , RGBHV , YUV , YC , COMPOSITION etc |
|
MTBF : ≥ 1000hours ; Life-span : 100,000hours |
|
Level up degree : pixel ≤ 0.5mm ; module < 1mm |
|
Uniformity : pixel and module uniformity brightness |
|
Malfunction dot rate :< 0.0001 |
|
Switch power load : 5V/40A |
|
Computer display mode : 1280x1024 |
Control distance : internet line : 100m ; single mode fiber:
20km ; multi mode fiber:500m |
Shenzhen Huaxia L&C Display Technology Co., Ltd(CLC display company), a LED display company located in Baoan district, Shenzhen. Based on our 3 factories(total 15200 square meters), we designs and develops visualization solutions for a variety of products selected from professional markets: Advertisement, Media, Sports, Entertainment, digital cinema, CCTV security, simulation & virtual reality. In these markets, Huaxia offers user-friendly imaging products that optimize productivity and business efficiency.
Integrating visualization technology requires specialist know-how and expertise and that's exactly what we can offer you - before, during and after the sale. We offers a complete range of high-impact video display systems, image processing and content management technology for permanent installations, rental and staging markets. Based on our staff with a couples of experience, We provide the right visualization technology to match your needs.
As a OEM/ODM factory, we are supplying both LED display and LED module to the overseas and domestic buyers. We supports our customers to finish more than 1, 500 events every year, which are from more than 60 countries and regions.
Main product list:
Indoor display, outdoor display, outdoor/indoor display mesh
Pixel pitch:
From P1.5, P1.875, P3.0, ...P31.25
Application locations:
Outdoor, Indoor and semi-outdoor
Application markets:
Advertisement, Media, Sports, Entertainment, Digital cinema, CCTV security, Simulation & virtual reality
