Specifications:
· Power: 6W/12W/18W
· LED Qty:30/60/90pcs
· Light Angle:120°
· Light Flux:430lm/980lm/1650lm
· Size:120×35mm/172x35mm/225x35mm
· Shape:Round/Square
· Color temperature:White(6500k)/Natural white(4200k)/Warm white(3000k)±200
· Input voltage: AC85-265V,50-60Hz Using temperature:-20-50
· Power factor: ≥0.9
· Power-supply efficiency(PE):≥88%
· CRI : Ra≥75
Feature:
1. The input line of the lamp plus fixed clamp, is not easy to fall off.
2. Specific stainless steel spring, no rust, not easy to deformation, high elasticity, high safety
3. Flat stainless steel screw, parallel with the lamp body.
Construction:
1. Using high lumen SMD 2835 light source.
2. High intensity aluminum shell, heat faster.
2. Using good reflectivity light leading board ,the light is more equally.
3.Low voltage and constant current driver ,no glare ,the light is soft.
4. Launch in 0.01sec,no flashing ,no noise ,no radiation .Energy saving ,belongs to grand environmental light.
5. This product can show high brightness ,without seeing the lamp itself.
Service:
Prompt response in 24hrs
MOQ=50pcs
Delivery in one week for samples and 4 weeks for shipment
warranty: 2 years, 100% replacement guarantee
Application of our LED Panel light:
1. Hotels
2. Conference/Meeting rooms
3. Factories&Offices
4. Commercial Purposes
5. Residential/Institution Buildings
6. Schools,Colleges&Universities
7. Hospitals
8. Pleaces where energy saving and high color rendering index lightings required
|
led panel light specification |
|
POWER |
6W |
12W |
18W |
|
LED QTY(pcs) |
30 |
60 |
90 |
|
Light Flux |
430LM |
980LM |
1650LM |
|
SMD TYPE |
SMD 2835 |
|
LIGHT ANGLE |
120° |
|
VOLTAGE |
90-265V |
|
COLOR |
3200k / 4200k / 6500k |
|
SHAPE |
ROUND & SQUARE |
|
SIZE(ROUND) |
120MM |
172MM |
225MM |
|
SIZE(SQUARE) |
120*120MM |
172*172MM |
225*225MM |
|
WORKING TEMPERATURE |
-20~50° |
|
POWER FACTOR |
≥0.9 |
|
Power-supply efficiency(PE) |
≥88% |
|
CRI |
Ra≥75 |
|
Certification |
CE,RoHS,ISO9001 |
|
Warranty |
can do 2 years or 3 years |
Bornyoung Lighting has put its main focus on the manufacturing of Energy Saving Lamp and LED since 2008. With its strong financial position and technical expertise, the company has contributed to the development of green technology worldwide.
We are located in Shaoxing, Zhejiang Province, we are able to produce 400, 000 lamps per month. Our products have passed CE, RoHS, EMC, GS, ISO9001-2000 certificates.
We guaranteed products at a competitive price and high quality. At present, our products have a very good sale in domestic and overseas market. We wish to cooperate with you to create a bright future and mutual benefit.
Much appreciation for your prompt attention in advance, we are eager to look forward to hearing from you soon.
