Applicable place
Suitable for flammable and explosive fields, used for various singular, outside the workplace, coal industry, sinopec, petrochina, electric power, metallurgy, cnooc, railway, steel, ship, troops, aeropace, public security fire control, chemical industry, government departments and large enterprise fixed lighting use need.
Features
1. This product has been in accordance with the authority of the state explosion mechanism, fully in accordance with the national standards for explosion proof production, intrinsically safe explosion-proof grade, using magnetic trigger, with excellent explosion-proof, anti-static effect, which can be used safely in all flammable and explosive places.
2. High energy memory free battery has a large capacity, long life, low self discharge rate, economy and environmental protection; special LED lamps with high light efficiency, low energy consumption, long service life.
3. Continuous working time of up to 11 hours, which can satisfy requirements on duty, also can be used as emergency lighting; only 4.5 hours charging time; a full charge, can use at any time within 6 months.
4. Imported high hardness alloy enclosure can withstand the strong collision and impact; waterproof, high temperature, high performance is good, can work normally in the 200 meters underwater and under various bad weather conditions.
5. Torch configuration over discharge, overcharge and short-circuit protection device, effectively protect the battery, prolong torch; Intellectual charger is also installed with short circuit protection and charging display apparatus.
6. The product size Φ 40*208mm, the weight is only 280g, very convenient to carry.
Main technical parameters
| Ex-mark | Exd IICT6 |
| Rated voltage | 7.2V |
| Rated capacity | 2Ah |
| Wording current | 350mA |
| Wording voltage | 3.3-3.5v |
| Life length | 100000h |
| Continuous discharge time | 9h |
| Dimension | 208*40mm |
| Total Weight | 0.28Kg |
| Normal charging time | 4.5h |
| Running down of battery | 5-6h |
| The service life of the battery | around 1000(circulate) |
