Home LED Light Products Dgx Outdoor P12 LED Display-03

Dgx Outdoor P12 LED Display-03

Dgx Outdoor P12 LED Display-03
Price: US $ 500-1000/Square Meter
Trade Terms: FOB,others
Min Order: 10/Square Meter
Pay Type: T/T
LED display(outdoor p12), 6944dots/sqm, 192*192mm 1) Types: Outdoor LED display screen, 2) Colors: Full color 3) High definition and high brightness; Long durability and high reliability 4) Advance video control system and Super input system 5) Audio and video interface of the system can offer vivid, complete and high quality LED display to TV broadcasting signal 6) Fit for various computer net 7) Standard connection socket 8) Easy installation, Low maintenance cost 9) Software for remote control of communication and scheduling 10) good heat emission capability 11) Customized design available 12) certification: CE and SGS. 13) Widely used in stage, concert, stadium, parties, bank, restaurant, station, shopping center, government, schools, and enterprise
1 Module Size 192mm * 192mm
2 Module resolution 16*16 pixels
3 Density 6944 dot / M2
4 Power consumption ≤1000w/m2
5 Display Luminance ≥5000cd/m2
6 Drive Mode constant 1/ 4 scan
7 Viewing Angle Horizontal :140°,vertical : 140°
8 Viewing Distance From 5 meters to 60 meters
9 Grey Scale red\green\blue ,256 gray scales respectively
10 Color 16.7 million
11 Change frame ≥100HZ
12 Scanning rate 180HZ
13 Screen life 50000-80000 hours
14 Screen MTBF 100000 hours
15 Blind rate ≤0.0002
16 Working Voltage AC220V±10%,50Hz
17 Control distance ≤100 meter with cat5 cable(MMF 500 m,SMF 20 000m )
18 System working
Environment temperature
-55 °C~ +85°C
19 System working
environment Humidity
10%_95%RH
20 Continuous working time 24hours /day
21 Color temperature 6000K±500
22 Information source Many kinds of signal access ,can input TV signal ,DVD
signal ,Computer signal,internet and other
23 Control graphics
technology
Intellective control technology, test-itself technology ,correct
technology.
24 Multimedia control
technology
Abundant multimedia video picture ,characters manifest function ,and
switch quickly function
25 Maintenance Pixel by pixel
26 Configuration Screen composed of the cabinets ,cabinets composed of the modules
27 Maintenance manner Reservation position is 45cm
28 Switch manner Computer control switch automatically
29 Remote management (extra charge,optional,default is cable control)) Remote control display system and operate
Prod Model: led display(outdoor p12)-03
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Pitch: 12mm
Tube Chip Color: Full Color
IP Rating: IP43
Pixel Configuration: 1R, 1G, 1B
Pixel Pitch: 12mm
Display Function: Video Display
Scanning Mode: 1/4 Scan
Certification: CE
Pixel Density: 6944 dot / m²
Average Power Consumption: 600W / m²
Shenzhen DGX TECHNOLOGY Co., Ltd. is a high -tech enterprise which specialize in LED RD, design, production, assembly and so on, DGX locate in Bao'an district of Shenzhen China which is established in 2008 and has got 150 employees.

Our major products are full color LED outdoor/indoor display screen, LED tube light, LED indoor decorating lighting, scenery lighting and building lighting.

DGX 's culture soul is "morals, development and promise", all of our employees echnics management, quality and service are based on this culture soul.

DGX' s LED display and lighting products apply to night club, KTV, disco, theatre, building, plaza, square, TV station, all the lighting, entertainment, and advertisement field, we have got high reputation in these industry.

DGX apply Taiwan and CREE LED chip to ensure the vivid video effect and Technicolor, we have got many successful project, in every China province, Australia, EU, America, Africa and so on.

DGX is famous for high quality, fast response after service.

DGX develop all the business by international eyesight and developing policy to push LED industry in China and all the world, we are looking forward to wining the future with all global customers.
