Home LED Light Products China IP67 Waterproof 110W LED Strip Light

China IP67 Waterproof 110W LED Strip Light

China IP67 Waterproof 110W LED Strip Light
Price: US $ 225-245/Piece
Trade Terms: FOB
Min Order: 1/Piece
Pay Type: L/C,T/T
Product description
1,N.A.S.A optical system,2-10 times brighter than led light
2,High lighting effect, up to 95%
3,angle can be 10,25,40,60,90,120 degree
4,Housing with pure aluminum material,very stable and strong
5,5 years warranty,and can be used for 10 years
6,Approved by CE,RoHS,ETL,DLC,and supported by IES,IP66

Packing information
All products packed with wooden box,safe and high-quality

Application
1,Gymnasium, Sports Stadium Lighting;
2,Gas Station, Petrol Station Conference Centers ,Garage Lighting, Canopy Lighting;
3,Parking Area, Garden Lighting;
4,Billboard Lighting, Flood Lighting;
5,Tunnel, Subway, Underground Lighting,Outdoor street and building light;
6,Warehouse, Storage Lighting, High Bay Lighting;
7,Yard, Square Lighting.

What we can do ?
To solve problems and make projects happen for customers
To increase product performance and raise industry standards


FAQ

1. How To Get Quotation
After browse our website, if you are interested in some of our products, you can send e-mail
Or can directly contact with us online through Skype
When you send inquiry, please kindly send your company and contact information. So, we can recommend appropriate products to you. We are also looking for serious and professional partners. So, we can provide more professional services.

2. How To Place Order
Step 1: you get quotation from our sales
Step 2: you send PO or follow information to our sales
1) Item number of products you order
2) Quantity
3) Buyer Name
4) Shipping destination and shipping method (if you are not sure, our sales will advise according to your order)
5) Consignee
Step 3: our sales will send PI(proforma invoice) to you, which include order details, shipment, payment and delivery information
Step 4: if you agrees to PI, then arrange payment.
Step 5: after we received payment, we will let you know and begin to arrange production.
Step 6: after shipment, we will send you tracking number(express), AWB(air cargo) or B/L(sea cargo)
Step 7: you get your order and check quality. If it's OK, order process end.

3. Warranty
5 years

4. Payment
For sample order, normally,we accept Paypal, Western Union and T/T(bank transfer
For bulk order, we accept T/T(bank transfer) ,Paypal,and Wesrtern Union.

5. Shipment
a. For sample order, normally we use courier like DHL, UPS, TNT, FEDEX, EMS.You can assign you own courier.
b. For batch order, air cargo or sea cargo is the best choice. You can also assign the forwarder to make the transportation.

TECHNICAL
ITEM IP66  f Waterproof  LED L L L L
ITEM NO LS-FL S110
Power110W
Light Source
Epistar  /B x rigelux  Power
Chip

Input Voltage
90 -2 65 VAC  50-60HZ
Power Factor (PF) ≥0.95
Power Efficiency≥ 90%
Color Index(CRI)Ra >65
Light Angle 10° ,40°,60°,90°
Color Temp:
2800-3500K
5000-6000K
6500-7500K

LED Luminous Efficiency
100lm / / / /  Watt
Luminous Flux (Typ.) 4000lm
Equal Flux (Typ.) *8000 lm
Life Span ≥  80000  hours
Work Temperature: -  25 ° C ~  55 ° C
Storage Temperature: -  40° C ~ 80° C
Working Humidity 10  %  ~   90  %   RH
IP RatingIP66
Light Attenuation(80000h)30%
Light Body Size (LxWxH)465x50x77mm
Lamp Net Weight1.9
Package Size: 565x100x100mm
Total Weight2.5



40W  LED  p Strip  t Light  t Test  Report
t Test  : Item:  40 t Watt  p Strip  Light
t Test  : Company:  t Independent  y Laboratory  Testing
t Test  : Date:  From  t Feb.1st  1 2011  o to  t Oct  t 11st  2011
. 1.  e Life  Span t Test  Project
t Test  Method:
Light Fixture maintains bright in constant temperature and humidity environment,
temperature range should be within 45+/-2 degree, relative humidity is no more than
60% ,wind speed is less than 0.05m/s. Light Fixture is driven of the constant temperature
and humidity environment, adjust the ambient temperature to 25+/-2 degree. The
measure it with power


Test
Hour(H)Light  Flux(LM)DC VoltageDC Current(A)
Preservation  e Rate  of
light

1
110000lm 31.3335100%
1000107800lm31.353598%
2000107360lm31.303597.6%
3000106150lm31.353596.5%
4000104500lm 31.283595%
5000103730lm31.373594.3%
6000102850lm31.373593.5%

Estimated  e life  Span:
According To energy star requirements for LED life Spain, light saving rate is 93.50%
for 6500hours and life span is greater than 80000 hours
e Failure  Determined:
When retention rate is less than 70%, we regard it as led failure. The Visible
brightness is observed obviously down, central color temperature shifts seriously, the
basic lighting requirements for customers or Users can not be satisfied, or it has bad effect
to the eyes of users. Failure time: generally 100000hours.
. 2.  c Opto-electric  t test  project:
p Lamp  Parameters:
Input Power AC(W) Rated 1050
Measured 1049
Power Factor Rated 0.95
Measured 0.95
Input Frequency (HZ) Rated 50~60
Measured 50
Color Temperature (K) Rated 2800-7500
Measured 6750
Luminous Flux (lm) Rated 1 10000
Measured 115400
Input V oltage (V) Rated 30-34
Measured 31.3
Input Current (A) Rated 35
Measured 35
Luminary Efficiency (lm/W) Rated 110
Measured 115
Color Index (RA) Rated 65
Measured 70.5


Test  Instruction
1. The Luminous surface of fixture is horizontal
2. LED Driver is inbuilt type.
3. Light Source: LS-HPEPY100M50CW-A11 10pcs
4. Keep the light on for 2 hours when measured; write down the numbers after the light
source is stable
5. Test Environment temperature: 25+/-1C, Humidity: 61+/-10% RH
6. Photometric Test Condition: Use The Sphere- Radiometer to test optical and color
Parameters: Integrating sphere diameter-1.5, inner ball coating is barium sulfate,reflection
rate 90-95% . Measuring method-4%,the spectrum range is 380-790nm
7. Uncertainty explanation: under impact from test environment and temperature, the
system inaccuracy of testing instruments will further impact the test results
d Referred  t test  standard: IES LM-78:2008, IES LM-79:2008, IES LM-80: 2008,
US Energy star, LED TEST(Version 2),CIE 127:2007,ISBN 978 3 901 906 589
Prod Model: LS-FLS110
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Item: IP66 F Waterproof LED L L L L
Light Source: Epistar /B X Rigelux Power Chip
Input Voltage: 90 -2 65 VAC
Power Factor (PF): >0.95
Power Efficiency: >90%
Power: 110
Voltage: 90-265
With rich and good experience in the LED lighting field, we have successfully acquire more market shares in around the world. As a professional manufacturer and distributor, we have received the great reputation for our reliable professional and classic services, especially for the progress we made in innovative products in LED illumination field. We have dedicated ourself to the world's more beautiful decorative lighting products. At the same time, we would offer the most competitive price to our customer so as to provide maximum value.

We always hold the below principles, which will enable us to make it better.

Top Quality

Every item we produce is of TOP quality, and this has been our basic policy after establishment of the company and the base of mutual beneficial relationship with our customers.

Reliable and Classic Service

Whenever and wherever you place the orders with us, your requirement for the soonest delivery will be guaranteed. A smooth logistic arrangement can be ensured. Under any conditions, you will receive our reply for any of your questions either by fax or by E-mail with-in 24 hours. Sufficient technical assistance and flexible sales policy will be provided in the actual business operation. The loyal service can go through all over the sales by offering efficient answer to the inquiry, arranging the prompt shipment and providing various supports after-sales.

Continuous Innovation

The innovation is always the first factor and the most important thing for us. The developing research in new items, applied products, structure of organization as well as more efficient operation has never ceased in our company. We sincerely hope that both of our suppliers and customers can be benefit from this innovation in any degree.

The most competitive price

The consolidate friendship and long-term business relationship with every customers is always our target, and we shall constantly dedicate ourbest efforts to provide the maximal value. With us, the most competitive price is provided while good quality is remained.
