Best Price P10 LED Indoor Nichia Display

Best Price P10 LED Indoor Nichia Display
Price: US $ 888-1988/Square Meter
Trade Terms: FOB,CIF,EXW
Min Order: 1/Square Meter
Pay Type: L/C,T/T,Paypal,Western Union
Indoor LED Display Board:
1. Certification: CE, RoHS, UL, SGS
2. Warranty: 7years
3. Support TV, S-Video, DVI, AVI, MOV.
4. High resolution, High brightness
DescriptionTechnical parameter
Unit moduleModule size320*160mm
Pixel pitch10mm
Pixel density10, 000dots/m2
Pixel configuration3 in 1
Led specificationSMD5050
Pixel resolutionW: 16dots*H: 16dots
CabinetDimension960mm*960mm*170mm
Cabinet materialAluminum
Weight45 kg/sqm
Quantities of module36pcs
Power supply6pcs
Thermal dischargeFan*2pcs
Total weight65kg
Best viewing angle10-100m
TemperatureStorage: -35~+85
Working: -35~+85
Thickness17cm can adjustable
Remarks: cabinet size can changed, upon project need.
PowerWorking voltageAC220V/110V± 10%
Average power consumption300-500W
Max. Power consumption≤ 1000W/sqm
Current≤ 20mA(single LED)
Control systemCPUPentium4 or above
Operating systemWIN98/2000/NT/XP
Control methodSynchronization
Main technical parameterDriving device1/4scanning
Drive typeConstant Current driver IC
Refresh frequency≥ 400Hz
Grey scale/colors256 levels of each color(R/G/B)/16.7M color
Brightness of white balanceMore than 10, 000cd/sqm
Brightness adjustment256 levels of each color(R/G/B)by software
Operating ambient humidity10%--95%
Video signalPAL/NTSC
Control systemDVI display card+full color controller card
MTBF≥ 10, 000hours
Life span≥ 100, 000hours
FlatnessTolerance of interpixel ≤ 0.3mm
Tolerance of modules clearance≤ 0.6mm
Power switchAutomatic switch
Display mode1024*768
Communication distanceUnshielded twisted pair net line transmission distance 100m, max transmission distance 200m.
Multi-mode Optic fiber transmission distance 500m; Single-mode optic fiber transmission distance 10KM
SoftwareLED media player
Prod Model: indoor p10
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Resolution Of Module: 16*32
Best Viewing Distance: >=10m
Horizonta L Viewing Angle: 140°
Brightness: 1400-9500
Gray Scale: 16bits Per Color
Frame Frequency: 60Hz
Refresh Frequency: >=300Hz
Working Temperature: -20&Deg-80&Deg
Mtbf: >10000h
Life Span: >100,000h
Tube Chip Color: Full Color
Display Function: Video Display
Pixel Pitch: 10mm
Pixel Configuration: 1R,1G,1B
Pixel Density: 10,000 dots / m²
Scanning Mode: 1/4 Scan
Application: Shopping Guide
IP Rating: IP43
Certification: CCC
Shenzhen Foxgolden Technology Limited, is one of the most impressing Hi-tech enterprises in China. Since 2004, we have been dedicating to the aim that making high quality products, and have been well integrated with R&D, production, project, capital and marketing.

As a professional and market-oriented LED display manufacturer, FOXGOLDEN not only keeps improving on normal LED display screen, enhances the product's cost-effective and overall market competitiveness, but also makes breakthrough progresses on special usages. Our products, with high quality and competitive prices, spread worldwide and earn excellent public reputation from both domestic and overseas market.

Foxgolden provides a full series of LED display products involving various single and dual color, text & image display; Indoor single & dual color, full color screen; Outdoor single & dual color, full color display; DOT matrix module display; Traffic applied product; And series of indoor & outdoor module.

Our company has provided our indoor & outdoor displays for various kinds of locations and events throughout the world. With high quality and perfect after-sale services, our professional products and solutions are highly complimented by the users, and we also earned high credibility from them.

With cultivation for high-quality production management team and project team, high quality products and local maintenance service; We achieved zero complaint in product quality for 3 constant years. That's why Foxgolden has received comprehensive attentions from LED industrial experts these years.
