Archon W106W Diving Light
OPERATING INSTRUCTIONS
PRODUCT SPECIFICATIONS
Model: W106W Underwater Photographing Light
LED: 100WSWC (Max 10000 Lumens)
Color temperature: 5000k
Runtime: High: 1-1.2 hrs, MID: 2 hrs, Low: 3 hrs.
Three output levels. High> Medium> Low
Reflector: Without reflector, for underwater photographing only
Lens: 8mm Polycarbonate Board
Body material: Durable aircraft-grade aluminum
Angle of light beam: 120°
Operation voltage: 18V to 26V.
Waterproof: 100 meters underwater
Surface treatment: Premium Type III hard-anodizing.
Color: Black
Battery: Li-ion battery pack, 25.2V, 4400mAh
With battery over-discharging protection, polarity reversing protection
Size: 300(length)*76mm (dia. Of head).
Weight: 800 grams(without battery pack); 1500 grams (with battery
Pack)
Underwater Weight: 750 grams (with battery pack)
BATTERY INSTALLATION
1. Remove the body by turning counter-clockwise
2. Remove used battery pack and replace with fresh battery pack as Shown by the polarity stickers.
3. Mount the body by turning clockwise. DO NOT ACTIVATE IT YET.
BATTERY CHARGING
1. Plug the charger in the wall power socket, the indicator light is green In the free-load status.
2. Insert the charger into the battery pack directly, .
3. The indicator light is red if the battery pack is not fully charged; It will Turn green after fully charged.
4. Take out the fully charged battery pack and use them in the diving Light.
ON/OFF
Turn the body clockwise until the light activates. DO NOT OVERTIGHTEN.
To turn the light off, back off the tail counter-clockwise until the light Goes off.
Continue to back off for approximately one full turn to eliminate the Possibility of the light activating accidentally in storage. For Underwater use, backing off too much will allow water to enter past the O-ring.
MODES CHANGING
Successive switch ON-OFF within two seconds to cycle through high, Medium, Low.
SCUBA DIVING APPLICATION
Check closely for cuts, scratches, or an otherwise damaged o-ring or Mating lens surface as this can cause the light to flood under pressure. Remove any salt deposits, sand, dirt, or other foreign matter from the O-ring sealing surfaces.
KEEP THE THREADS, O-RING GROOVE LUBRICATED WITH
SILICONE GREASE.
CAUTION
If the light is not to be used for some time, remove the battery pack to Prevent possible leakage or corrosion. Please remove the battery back During transportation to prevent it from misoperation. WARRANTY RETURN POLICY
Please contact your local distributor or retailer for information on how To handle your warranty items.
REPLACEMENT PARTS
CAT# DESCRIPTION
