Home LED Light Products Alumium Green Color 3*3W Garden Spike LED Light

Alumium Green Color 3*3W Garden Spike LED Light

Alumium Green Color 3*3W Garden Spike LED Light
Price: US $ 165-185/Piece
Trade Terms: FOB,CIF,EXW
Min Order: 100/Piece
Pay Type: L/C,T/T
Alumium Green Color 3*3W Garden Spike LED Light

Specification
LED Lamp: USA CREE LED, 30W/12V, Lumen: 3500lm, 90-100lm/W 30W to achieve 37LUX at 6m high, ≥ 50000hours
Solar panel: 100W/17.5V, Poly solar panel, more than 25 years
Gel Battery: 120AH/12V, deep cycle, maintenance free, 3-5 years
Controller: 10A/12V, optical & time control(Germany Phocos) water proof protection grade: IP68, 8-10years
Pole: 6M cylindrical, hot DIP galvanization(85μ M) and spraying power. Down Diameter: 160mm, 20years
Working time: 8h/day, it can be used 3-4days without sunshine, or as your demand to design
PVC Battery box: For 120ah*1PCS battery, Underground, 10-15years

Advantage
1. The Most Competitive Price.
2. Customized Solar Pathway Light for You.
3. Attentive Customer Service.

Why choose us
More than 10 years experience of solar street light
1, Focus --- focus on R & D & production of solar LED street light for 10 years;
2, Projects--- large quantity of successful projects at home and abroad;
3, Quality--- all parts are from well-know enterprise and international famous brand;
4, Free derdesign--- no charge of all pre-project design;
5, After sales service--- long warranty relief you from troubles in application

Applications In Many Occasions:
Solar Street Lights; Solar Streetlights; Solar Street Lamps;
Solar Street Lighting; Solar Street Lighting System;
Solar Powered Street Lights; Solar Powered Street Lamps;
Solar Lights; Solar Lamps; Solar Lighting; Solar Lighting System;
Solar Powered Lighting; Solar Powered Lights; Solar Lights Manufacturer;
Solar Illuminations; Solar Illuminated System;
Solar Road Lights; Solar Road Lamps;
Solar LED Lights; Solar LED Street Lights; Solar LED Street Lighting;
Solar Powered LED Street Lights; Solar LED Lamps;
LPS Solar Street Light; Sox Solar Street Light; Sodium Solar Street Light;
Solar Post Lights; Solar Post Lamps
Photovoltaic Lighting; Off Grid Lighting; Off Grid Solar Lighting
Solar Security Lights; Solar Path Lights;

FAQ:
1. Terms: FOB Guangzhou
2. Production time: 20-25 days
3. Payment: By T/T, 30% down payment and the balance effected before delivery;
4. Warranty: 2 year;
5. Packing: Packed by Carton toughed with Middle Density Fibreboard;
6. The parameter can be adjusted as your demand.

Rainbow Liang
Lingda New Energy
LED light, solar street light, solar system
Professional services, high-quality products
Δ ADVANTAGE:
      1. USACree/Bridgelux Q5 LED, multi-functional
    2. Environment protection, Energy saving
    3. Easy installation, Long life span
    4. Free of maintenance
    5. Low voltage, safe and reliable
    6. Independence operation system
    7. Applications: Street, Garden, Public square, Park

Δ MATERAILS:
    1. Lamp Body:
          high pressure die-cast aluminum, corrosion resistant house, high in strength and compact in structure;
          The surface is static spray-paint, high temperature and weather resistant frame tenure, colorful;
    2. Pole Material: SS400 steel, pot galvanizing, plastic spray treatment.

Δ Working time: 10hr/d, 6H full-energy mode + 4H energy-saving mode, 3 continued overcast & raining days.

Δ LED LIGHT SPECIFICATIONS
Model No. SLD05-30W
Lamp power 30W
LED quantity 30pcs*1W
Voltage (V) DC12V
Luminous Efficiency 80~90 LM/W
Color temp. (K) 6500
Ilumination (LUX) 35LUX   8m
Beam angle 135°
Working temp. (º C) -15~+55
IP grade IP65
Size (cm) 63.5*27*19.5
Weight (KG) 7.5

Δ SOLAR PANEL SPECIFICATIONS
Model SM45 series
Nominal Power(W) 45W/12V
cell mono or poly, conversion efficiency: 17%
Arrangement way 6*9
System voltage(V) 12/24V
Pmax(W) 45W
Vmp(v) 17.2V
Imp(A)   2.91A
Voc(V) 21.6
Isc(A) 3.31A
Dimension of Module(mm) 856*554*40
Weight(kg) 6
Cell Mono/Poly

Δ SOLAR CONTROLLER 10A/24V SPECIFICATIONS
ITEM NO. 24V / 10A
Rated voltage(VDC) 24
Rated current(A) 15
Charge recommended max. current(A) 15
The biggest open-circuit voltage(V) 28.8
Charge(V) Protection 28.8± 0.2
Floating charge 23.6~26.2
Restore 23.6± 0.2
Temperature compensation -30mV/º C
Low voltage(V) disconnecct 21.6± 0.2
Restore 23.6± 0.2
Current without load (mA) 20
Application ambient temperature -35º C~+55º C
Application altitude (m) ≤ 5000
Size (mm) 140*90*26
Weight (KG) 0.25
Perfect protect function:
  1. Battery reverse connection protection
  2. Solar panel reverse polarity connection protection
  3. Over load and short circuit protection
  4. Back flow from battery to solar module protection
  5. Battery open circuit protection
  6. Lighting surge protection(in case necessary)
  7. Over-charging and over-discharging protection
  8. LED display
  9. Thunder strike protection;
  10. Time control and light control.

Δ Battery 12V65AH Maintenance-free Lead-acid SPECIFICATIONS
Nominal Voltage 12V
Nominal Capacity (10HR) 65AH
Dimension (single) Length 349± 2mm
Width 167± 2mm
Container height 174± 2mm
Total Height (with terminal) 174± 2mm
Weight Approx 21.4kg
Standard Terminal F11(standard)

Δ Battery  Box Location Optional
    1: underground
    2: on top of the pole
    3: at root of pole(have A and B design as following)

Δ Packing Information
Parts Qty Pack mode Size(cm) Weight(kg) 40 HQ Container (sets)
Pole 1 Poly 800*40*40 260 90
LED Lamp 1 carton & poly 73*37*30 10
Solar panel 1 carton & poly 130*90*14 15
Solar controller 1 Colar box 15*10*3 0.3
Batteries 1 carton & poly 39*21*25 22
Batteries box 1 carton 45*28*28 8
wire 1 carton 50*50*80 10

Δ NOTICE: The specicification can be changed and designned according to customers requirements. Example,
Example:
                                1. Pole height and color;
                                2. LED light power and brightness
                                3. Solar panel dimension
                                4. Battery capacity and installing location


Prod Model: SLD-SL-211
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Input Voltage(V): 12V
Lamp Luminous Efficiency(Lm/W): 100
Working Temperature: -20 - +60
Item Type: Solar Street Light
Color Temperature: 3000-3500k/6000-6500k
Color Temperature(Cct): Cool & Warm Color Available
Lamp Luminous Flux(Lm): 900-1000lm
Place Of Origin: Guangdong China (Mainland)
Solar Street Light Viewing Angle: 120°
Packaging Details: Standard Safe Export Packing
Light Type: LED
IP Rating: IP65
Voltage: 220V
Material: Aluminum
Guangzhou Lingda New Energy Technology Co., Ltd.Committed to the application and promotion of renewable energy, providing the society with various products with high energy efficiency, environmental protection, energy saving.

We are engaged in R&D, manufacturing, and marketing of solar street light, solar garden light, LED light, solar power system, solar module, solar collector and so on.

Our staff of sales and technical support is available to help you in selecting the right solution for your application as well as to provide you with samples of our products for evaluation.At LingDa, we are committed to providing the highest level of customer service, competitive pricing, speedy delivery and a comprehensive, cutting-edge product offering.Our ultimate goal is your satisfaction.

LingDa has earned the reputation as a premium brand known for exceptional quality, consistency and innovation.We pride ourselves on being able to offer the latest technologies in solar lighting...
