Advertising P8 Outdoor RGB LED Display for Commercial

Advertising P8 Outdoor RGB LED Display for Commercial
Price: US $ 24.67-26.075/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 100/Piece
Pay Type: T/T,Western Union
P8 Full Color Outdoor LED Display (256*128mm LED Display)

A. High brightness with low power comsumption.
B. Stabel lifespan.
C. Flatness gap between cabinets.
D. Standarlization frame in case update.
E. Easy installation charactristic.

Brilliantopto Group is specialized in LED display, LED display screen, outdoor led display, advertising led display and LED billboard. We offer good products and customized solution that meet the need of our customers.

The LED application products research and develop by Brilliantopto Group has full range and structure diversification, its products cover LED full color display for indoor and outdoor, LED advertisement display, LED stage display, LED irregular-shape display, LED display for taxi, LED sports display, LED traffic information display, which has been dominated in demestic and international market in this industry.




Our P8 Outdoor led display Features
1) High brightness and be adjustable, meets the need of the changing requirement of customer in environment.
2) Having good lightening accordance and no mosaic.
3) Using virtual pixels, better viewing effect for both text & graphic and video.
4) Having larger viewing angle: Horizontal angle 120 degree / elevation angle 90 degree. Getting vivid effect within any position of the viewing range.
5) Any LED in each pixel can be respectively repaired, which reduce the cost of the display maitenance.
6) Good heat emission capability
7) Environmental-friendly.
Pixel Pitch 8mm
Module Size(W×H) 256mm*128mm
Module Resolution(W×H) 32*16 dots
Pixel Density 15625 (dots/ m2)
Lamp Origin Epistar
Pixel Configuration 1R1G1B
Led Specification DIP246
Gray Level/ Color 65536 lever /16.7M
Brightness ≥8000cd/m2
Best view angle Horizon: 120°                            Vertical : 90°
Control method Synchronous
Scanning method 1/4 constant current
Power consumption Average: 550w/m2                        Max : 1100w/m2
Best viewing distance 6~150m
Lifespan ≥100,000 H
MTBF ≥10,000H
Frame frequency ≥60HZ
Refresh frequency ≥300HZ
System Working Temperature –20°C ~ 50°C
System Working Humidity 10 ~ 90%RH
Power 5V/40A
Module weight 595g/pc
Brightness control lever 0 ~ 100 lever
Maintenance way Rear access
Environment temperature -40°C ~ +85°C
Suitable voltage DC5V
Spending card kilomega network card
Video signal PAL/NTSC
Working voltage 220V±10%
Prod Model: P8
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
DOT Pitch: 8mm
Module Dimension: 256*128mm
Module Resolution: 32*16
DOT Density: 15625dots/M2
Brightness: 7800CD/Sqm
LED Specification: 1r1g1b
Pixel Configuration: DIP246
Driving IC: Mbi5024
Scan Mode: 1/4scanning
LED Lamp Brand: Epistar
Display Type: LED Video Display
Tube Chip Color: Full Color
IP Rating: IP65
Pixel Configuration: 1R, 1G, 1B
Display Function: Video Display
Scanning Mode: 1/4 Scan
Certification: ISO9001,IP65,FCC
Average Power Consumption: 350W / m²
Pixel Pitch: 8mm
Pixel Density: 15625dots/Sqm
Jingcai (Fujian) Photoelectric Co., Ltd. Was founded in 2005, with a registered capital of 20.18 million Yuan, a workshop covering an area of 20000 square meters and independent living and production places. Our company is professional in the development and manufacture of LED display systems. Our company technology strength is among the front row in this area, with a vigorous team.

In March, 2011, our company independently researched and developed a full-color formal P16 LED display, which can completely replace the current market single color LED displays, being the perfect choice in the next line of LED display market. In June, 2011, after designing P10 optical modules, we ceremoniously rolled out P10 light module series, which can effectively enhance the efficacy by above 10% and can effectively avoid a screen phenomenon. In August, 2011, our company took the lead in Quanzhou LED industry technology innovation strategy alliance. As the President unit, our company set up "Quanzhou LED Technology Research Center", featuring the national quality supervision center. Our company has many experts and professors from Xiamen University Semiconductor Research Center, Fuzhou University and Beijing University Institute of Photoelectricity for our research center technology consultation to comprehensively promote Quanzhou LED industry. In November, 2011, relying on our strong technical research and development team, we made a new generation of international leading 3D display screens.

Through six years of unremitting efforts, our company has successively obtained such honorary titles as The State Ministry Of Small-Sized And Medium-Sized Enterprise Technology Innovation Fund Project Unit, Small-Sized And Medium-Sized Enterprise In Fujian Province Technology Innovation Fund Project Unit, ISO9001 International Quality Management System Authentication Enterprise, CCC China National Mandatory Product Certification Enterprise, CE Compulsory Product Certification Enterprise, FCC Anti-Radiation Product Authentication Enterprise, RoHS Lead-Free Environmental Protection Product Authentication Enterprise, IP65 Waterproof and Dustproof Product Authentication Enterprise, Chinese Optical Optoelectronic Industry Member Unit, National Taxpayer Service Work Outstanding Member Unit, Unit With 15 Independent Research And Development Patents Of The State Intellectual Property Office, Fujian Quality And Right Protection Service (Member) Unit, Fujian Integrity And Labor Advocate Unit, Quanzhou Industry And Commerce Credit Good Enterprise, Quanzhou Creditable Unit, Quanzhou LED Technology Research Center and Quanzhou LED Industry Technology Innovation Strategy Alliance Chairman Unit.

Our company always implements our development target and insists on the tenet of "customers are the growing power source". Our company has a perfect after-sales service system, truly realizing that customers are the centers of the market marketing model.

Through our efforts, our products have been sold well in Europe, North America, Australia, the Middle East and Southeast Asia. Our company has set up stable sales agents in the corresponding areas. Our company sincerely hope to cooperate with LED display system talents and dealers for common development and for the development of LED display systems.
