Products specification:
Voltage: AC110V-220V/50HZ-60HZ
Power consumption: 200W
Control system: Automatic procedures, DMX512, music
Control Channels: 16CH
Lamp: 1x90W White LED
Color wheel: 7 colors + open
Gobo wheel: 8gobos + open (Rotation)
Prism: 3 prism(Rotation)
Lamp control function via the controller
Pan 540 8 or 16 bit resolution
Tilt 270 8 or 16 bit resolution
Strobe: 1-18times/s
Automatic Pan and Tilt reposioning by photoelectric
Dimmer: 0-100% mechannical linear dimming
Focus
DFC
Photometrics
90W:
1M 63000LUX
2M 15300LUX
3M 6900LUX
5M 2800LUX
8M 1700LUX
| channel | Function explanation | Value |
| CH1 | Dimmer | 0 : OFF 1-255 : Dimmer |
| CH2 | Strobe | 0 : OFF 1-255 : Strobe |
| CH3 | Color Wheel | 0-255 Color Wheel |
| CH4 | Color Wheel 16 bit | 0-255 Color Wheel 16bit |
| CH5 | Pan | 0 : OFF 1-255 Pan ( 540° ) |
| CH6 | Pan 16bit | 0 : OFF 1-255 Pan 16bit |
| CH7 | Tilt | 0 : OFF 1-255 Tilt ( 270° ) |
| CH8 | Tilt 16bit | 0 : OFF 1-255 Tilt 16bit |
| CH9 | Pan/Tilt Speed | 0 : OFF 1-255 Pan/Tilt Speed |
| CH10 | Gobo wheel | 0-255 : Gobo wheel |
| CH11 | Gobo wheel rotation | 0--7 : OFF 8-255 Gobo wheel rotation |
| CH12 | Focus | 0 : OFF 1-255 : Focus |
| CH13 | Prism | 0-127 : OFF 128-255 : Prism |
| CH14 | Prism rotation | 0-255 : Prism rotation |
| CH15 | Vector mode | 0-127 : OFF 128-255 : Vector mode |
| CH16 | Rest | 0-127 : OFF 128-255 : Rest |
