8w led street lightCan support 6 days rainy day solar street light , integrate Solar panel+ LED Panel solar street light , Battery can be replaceable solar street light .
Wireless all in one solar led street light, small volume solar led street light ,smart design solar led street light ....
Description:
1. All in one Solar garden&street lights, New invention patent products.
2. From 8W to 40W
3. Integration design, put solar panel, Led lamp, battery and cotroller all in a box, without any cable.
4. What you need to do when you receive them is to put them on the pole or wall, easy to ship, install and maintain.
Parameters:
Integrated Solar garden light (8W) | Model:KSIL-08 |
Solar panel | Max power | 18V15W (high efficiency monocrystalline silicon) |
Life time | 25 years |
Battery | Type | lithium battery |
Life time | 5 years |
LED Lamp (without sensor) | Max power | 12V 8W |
led chip brand | Epistar from Taiwan with high brightness |
lumen (LM) | 800-880lm |
Life time | 50000hours |
Viewing Angle | 120° |
Charge time | by sun | 6hours |
Discharge time | full power | 12hours |
half power | 24hours |
working Temperature | range( °C ) | -20°C~+60°C |
colour temperature | range(k) | 6000k |
mounting height | range (m) | 3-4m |
space between light | range (m) | 8-10m |
Lamps material of main | aluminium alloy |
Certificate | CE / ROHS / IP65 |
warranty period | 2years |
Packing & Weight | product/packing size | 515*320*52mm / 530*390*140MM |
product/packing weight | 5.5kg / 6.5kg |
packing box | neutral |
Corton size | 560*W570*H410MM |
Q'ty/ctn | 4sets/ctn |
GW.for corton | 26kg |
Packs Containers | 20GP | 933pcs |
40GP | 1933pcs |
Features:
1. Integrated design without line, using wood,bamboo of lamstandard with low cost.
2. Using solar power, Led lamp for saving energy.
3. Using high power capacity and long life Lithium Iron Phosphate Battery.
4. Rain-proof structure
5. Main structure is made by alloy materialfor anti crossion
6. With different power control. Reducing luminance auotmatically.
Applications:
Suitable for most of the streets, residential district road, industrial zong road, square, park, school, campus, farm, villas, gardens and other places of road lighting.
Advantage of KINGSUN
For the latest Integration style in the world, hottest selling products in many countries,
so far no more than 3 companies to produce this kinds of products in the world, and
we have more competitive price and productive power in China, the main advantage as below:
1. Without pole, Integration design, easy to carry, put solar panel, LED lamp, battery and controller all in one, without any cable;
2. Using high capacity and long life of lithium iron phosphate battery,service life 5 years, can resist high temperature and low temperature, can ensure the long service life of the whole product;
3. Easy to maintain,the battery and light are the direct inserted & pluck type, can complete the main maintain by yourself in the future when the battery or light source need to be replaced, don't need a
professional personage to do maintenance.
Brief Description:
Type: Street lights, Garden lights
Mounting Height: 2-3.5 metersNet Weight: 6 kg
LED Lumen: 900-950LM
Applications: gardens, streets, roads, community, parks, parking etc..
The Main Parameters:
1. Material: Aluminum
2. Solar Panel: 18V 20W (imported monocrystalline solar panels)
3. LED Brand: Bridgelux (12V 8W 900-950LM)
4. Battery: Lithium Battery 9AH
5. Mounting Height: 2-3.5 meters
6. Working Time: 40-50 hours
7. Working Temperature: -30 ºC ~ + 60 ºC
Packing Information:
1. Product Size: 480*440*50 mm
2. N.W / G.W: 6 kg / 7 kg
3. Carton Size: 550*450*150 mm
4. Quantity / Box: 1 set / box
5. Loading Capacity: 750 sets / 20'GP,1890 sets / 40'HC
