80w Wind solar hybrid LED street light
Features:
MODEL: WS8M-50W
Application: two-lane road, interval 25meters.
Continuous working days: 3-5 days in rainy or no wind condition.
Work mode: full power 5hours +75% power 4hours +50% power 3hours.
Work condition: average wind speed above 3.5m/s , effective sunshine time 4.5hours per day.
Working temperature: -20ºC~40ºC.
Warranty: 3years for wind turbine and solar panel, 1year for the other parts.
Different Models to choose:
1,50W
2,80W
Main parts:
Wind turbine | Mini300w |
LED light | SN-50WLED |
Solar panel | SP-150W |
Solar controller | SDB10A |
Pole | P8M-4.0 |
Accessory and cables | B8M |
Battery | CNL-150AH |
Battery box | BB-150 |
Detail Specification:
1,Wind turbine-Mini300w
Rated power 300w;
Rated voltage: DC12V;
Blades:3 Pcs Nylon Fiber
Start-Up Wind Speed: 2.0 ( m/s)
Cut-In Wind Speed: 2.5(m/s)
Rotor Diameter: 1.16 m
Body: Cast aluminum
Mount: 1.9 inch (48 mm) OD pipe
Working temperature:-40ºC~ 150ºC
Survival Wind Speed: 50 m/s
2,LED light-SN-50WLED
50W,DC12V,5000Lm
LED chip from Bridgelux, USA
Colour temperature: 4500-6500K
Lifespan: 50000hours
Working temperature: -40ºC~+70ºC
Water proof: IP67
Aluminium alloy shell
Unique acicular radiator
3,Solar panel-SP-150W
Monocrystalline silicon solar panel
Dimension: 1580*808*35mm
Vmp:18.3V
Imp:8.2A
Voc:23.5V
Isc:8.8A
Warranty: output power more than80% within 25years.
Certificate: CE, TUV.
4,Solar controller-SDB10A
12/24V auto rebognition, 10A
Built-in LED driver
Digital tube display
Charge mode: PWM
Water proof: IP68
Work mode: Light control + time control
Default setting: full power 5hours +75% power 4hours +50% power 3hours.
Overcharge, discharge, electronic short-circuit, overload protection, reverse connection preventing function.
5,Pole-P8M-4.0
Pole height:8m Light height: 6m
Thickness: 4.0mm cone pole, high quality steel.
Pole top diameter ¢80mm, bottom diameter ¢190mm.
Light arm is 1200mm long.
Baseboard size 400×400×16mm, 4 screwholes, distance:300×300mm.
Hot dip galvanizing 85um,antirust processed, spray outdoor fluorocarbon paint.
6,Accessory and cables-B8M
3*4square meter:10m,
2*2.5square meter:10m,
2*4square meter:5m,
all the cables will be connected well to controller before shipment, it is convenient for installation.
7,Battery-CNL-150AH
GEL battery
12V, 150AH
Working temperature: -30ºC~55ºC
Lifespan: 5-8years
Top quality.
8,Battery box-BB-150
Battery buried boxes
waterproof
anti-corrosion
battery thermostat
FAQ:
1,Does it work on foreland?
Yes, it is suitable for marine. The shell material is Aluminium alloy , the inside components has anti-corrosion treatment. The waterproof is IP65.
3,How long it can work in ?
it can work continuously in 3-5 rainy days.
