Led light manufacturers and factory

Home LED Light Products 5W Integrated Mini Solar Powered LED Light

5W Integrated Mini Solar Powered LED Light

5W Integrated Mini Solar Powered LED Light
Price: US $ 50/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 10/Piece
Pay Type: T/T,Paypal,Western Union

2015 HOT selling product!


5w integrated mini solar powered led light

-------------------------------------------------------------------------------------------------------------------
Models:

5w(portable),8w,12w,15w,20w,25w,30w,40w,50w,60w
-------------------------------------------------------------------------------------------------------------------

Features
1. All in one/ integrated design
2. PIR motion sensor, auto work with solar power
3. Easy installation without wires
4. Lithum-ion LiFePO4 battery, Modularity design and easy to replace.
5. Work temp from -20°C to +60°C
6. LED chip from famous brand EPISTAR, BRIDGELUX
7. Warranty for 3 years
8. IP65/CE/ROHS

 -------------------------------------------------------------------------------------------------------------------

Parameters

8w,12w,15w

Model
NSP08 (with sensor)NSP12 (with sensor)NSP15 (with sensor)
LED LightMax power12V 8W12V 12W12V 15W
Led chipEPISTAR, Taiwan
Lumen (LM)800-880Lm1200-1320Lm1500-1650Lm
Life time50,000hours
Solar panelMax power18V/15W18V/18W18V/25W
Solar cellHigh efficiency, Mono
Life time25years
BatteryCapacity6AH6AH10AH
TypeLithum-ion LiFePO4
Life time5 years
ChargingBy sun6-10 hours effective sunlight
LightingDimming power>24 hours
Work tempRange(ºC)Charging:0ºC~+60ºC, discharging: -20ºC~+60ºC storage:0ºC~+45ºC
Colour tempRange(k)6000-6500k
HeightRange (m)3-4m3-4m4-5m
SpacingRange (m)8-10m8-10m10-15m
Work modeCustomized availableLight on at dusk, light off at dawn auto. PIR motion sensor detection. Full power lighting when a human move in the sensors range. 30% power lighting when a human move out.
MaterialAluminium alloy
CertificateCE / ROHS / IP65
Warranty3years
Packing & WeightProduct size(mm) 504*325*85746*325*135
Product weight6.5kg6.5kg8.2 kg
Carton size(mm)560*390*150560*390*150815*390*210
GW .for carton7kg7kg9.3 kg
Container Load20GP915sets915sets462sets
40HQ2193sets2193sets1118sets


20w,25w,30w,40w

Model
NSP20 (with sensor)NSP25 (with sensor)NSP30 (with sensor)NSP40 (with sensor)
LED LightMax power12V 20W12V 25W12V 30W12V 40W
Led chipBridgelux , USA
Lumen (LM)2400-2600Lm3000-3250Lm3600-3900Lm4800-5200Lm
Life time50,000hours
Solar panelMax power18V/45W18V/50W18V/60W18V/60W
Solar cellHigh efficiency, Mono
Life time25years
BatteryCapacity18AH21AH21AH24AH
TypeLithum-ion LiFePO4
Life time5 years
ChargingBy sun6-10 hours effective sunlight
LightingDimming power>20hours
Work tempRange(ºC)Charging:0ºC~+60ºC, discharging: -20ºC~+60ºC storage:0ºC~+45ºC
Colour tempRange(k)6000-6500k
HeightRange (m)5-6m5-6m6-7m6-7m
SpacingRange (m)18-20m18-20m20-25m20-25m
Work modeCustomized availableLight on at dusk, light off at dawn auto. PIR motion sensor detection. Full power lighting when a human move in the sensors range. 30% power lighting when a human move out.
MaterialAluminium alloy
CertificateCE / ROHS / IP65
Warranty3years
Packing& WeightProduct size(mm)1130*330*130
Product weight17.8kg18.3kg18.7kg19kg
Carton size(mm)1190*390*220
GW .for carton18kg19kg19kg20kg
Container load20GP230sets230sets230sets230sets
40HQ600sets600sets600sets600sets


50w,60w

Model
NSP50 (no sensor)NSP60 (no sensor)
LED LightMax power12V 50W12V 60W
Led chipBridgelux , USA
Lumen (LM)6000Lm7200Lm
Life time50,000hours
Solar panelMax power18V/80W18V/90W
Solar cellHigh efficiency, Mono
Life time25years
BatteryCapacity39AH42AH
TypeLithum-ion LiFePO4
Life time5 years
ChargingBy sun6-10 hours effective sunlight
Lightingdischarge>12hours>12hours
Work tempRange(ºC)Charging:0ºC~+60ºC, discharging: -20ºC~+60ºC storage:0ºC~+45ºC
Colour tempRange(k)6000-6500k
HeightRange (m)8-9m8-9m
SpacingRange (m)25-30m25-30m
Work modeCustomized availableTime control, Full power +dimmingTime control, Full power +dimming
MaterialAluminium alloy
CertificateCE / ROHS / IP65
Warranty3years
Packing & WeightProduct size(mm)1080*450*1531080*450*153
Product weight24kg26 kg
Carton size(mm)1190*520*2201190*520*220
GW .for carton24.5kg26.5kg
Packs Containers20GP231sets231sets
40HQ516sets516sets


-------------------------------------------------------------------------------------------------------------------

Packing: cartons with EPE protection

-------------------------------------------------------------------------------------------------------------------

 Why choose us as your long-terms partner?
 1. Over 10 years professional experience of producing and exporting solar&wind products.
2. Partner of F.A.O. (Food and Agriculture Organization)
3. Own technical team
4. High standard quality control program
5. Excellent speed service always

-----------------------------------------------------------------------------------------------------------------

Company introduction


COMMERCIAL ENERGY GROUP LIMITED
is an energy-saving technology pioneer company, engaged in develop and apply wind power generator and solar system. Located in the QINGDAO Development Zone nearby Qingdao port, the company enjoys an excellent traffic convenience.
In response the call of government concerning on energy-saving & emissions reduction, we majorly focus on the development of wind solar power system. Based on radical innovatory design concept and high-tech application, make fully use of the green, clean energy to achieve zero power consumption, zero emissions, zero pollution.
Guided by the principle of "advanced technology,exquisite product and competent manufacturing",the company is proceeding with the mission of energy saving and green planet building based on the spirit of credit,innovation,hard working and social responsibility.

-----------------------------------------------------------------------------------------------------------------

What's integrated solar LED street light?

Traditional solar system includes so many parts: traditional lamp ( or LED lamp), solar panel, lead-acid battery, controller, solar panel brackets, battery cabinets. The volume is very large, therefore freight charge is very high, and labor cost of mounting is also very high.

But NEWSKY POWER integrated solar LED street lights solve all the above problems and troubles.

Our unique design is to combine all the necessary parts in one unit. Since we use a light-weight lithium battery instead of lead-acid battery, and design the solar panel together with the LED street lamp. So our solar LED street light looks like a normal LED street light.

As no wires needed,just install light on pole,wall even trees,and press the button,that's all.Let it enjoy sunshine in day, it can bring light to you at night.
it widely used for street,path,garden,square,yard,car depot,marine...

In these two years, NEWSKY POWER integrated solar LED street light is trending and welcomed by global clients. If you are interested in our models, and if your area has abundant sunshine, please contact us and try out our integrated solar LED street light, which helps you to save money and energy.


-----------------------------------------------------------------------------------------------------------------

RFQ


1.What's the meaning of ALL IN ONE?
All quality parts includes Lithum-ion LiFePO4 battery, mono solar panel, LED chip and infrared sensor are built-in.

2. what's the operation way?
NSP8W-NSP40W: Light on at dusk, light off at dawn auto. PIR motion sensor detection . Full power lighting when a human move in the sensors range. 30% power lighting when a human move out.
NSP50W-NSP60W: Light on at dusk, light off at dawn auto .Time control.

3.How long it works at night and rainy days?
It can work all night long auto, it can work for 3-4 rainy days with full charged battery.

4. Does it work in low temperature area?
Charging:0ºC~+60ºC, discharging: -20ºC~+60ºC, storage:0ºC~+45ºC
higher than 0ºC in day and higher than -20ºC at night is OK.

5. how about works on seafront?
It's no problem used for seafront, as the shell material is aluminium alloy, all inside components are anti-corrosion. The waterproof is IP65.

6. What's the lifetime of battery and how shall we replace it?
The lifespan of battery is 5years. It is very easy to replace it. we could provide photos for your reference.

7. Could you accept OEM or ODM production?
Yes. of course, welcome contact us with your detailed inquiry.

8.Can you offer sample?
Yes, generally, sample will be delivered by international express, please let us have your postal code, thanks.

-----------------------------------------------------------------------------------------------------------------

CONTACT US

Una Liu
Qingdao Commercial Energy Electronics Co.,Ltd.
Tel : +86-532-86943160
Fax: +86-532-86936604
Mobile: +86-13969-820087
email: sales02@newskypower.com
www.newskypower.com
Prod Model: 5w
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Iterm: All in One Integrated
Models: Nsp05
LED Max Power: 12V 5W
Lumen (Lm): 3000
Life Time Of LED(Hours): 50000
Solar Panel Capacity: 18V 9W
Battery Capacity: 4ah
Battery Type: Lithum-Ion LiFePO4
Colour Temp Range(K): 6000-6500k
Pole Height(M): 0.8-4m
Power: ≤5W
Light Type: Solar
Voltage: 12/24V
Charging Time (',H): 6
Usage: Square
Lamp Body Material: Aluminum Alloy
Color Temperature: Cool White
IP Rating: IP65
Certification: RoHS
Light Source: LED Lamp
With Light Source: With Light Source
Technics: None
Illumination Time: 3-4days Night
Cell Type: Lithum-Ion LiFePO4 Battery
Qingdao commercial energy electronics Co., Ltd is subsidiary corporation of Commercial energy group limited, We are manufacturer of solar and wind products over 7years with well-equipped testing facilities and strong technical force. Our main products are all in one solar street light, MPPT solar charge controller, Phocos solar charge controller, solar refrigerator & freezer, wind turbine.

"NEWSKY POWER" is our brand which is one of the famous trademarks of China. With world advanced quality and technology, the products enjoy high reputation and wide influence in the domestic and overseas markets. It occupies most of the consumption market with its high product quality and sincere service

Thanks to its strong professional technical strength, strict quality management system, measuring and inspection system, standardization system, informatization system and modernized scientific management means, it exerts the potential advantages of sustainable development and undisputedly ranks the leading position in the same industry, becoming an acknowledged leading enterprise and excellent representative in China renewable industry.

We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success.
