PRODUCT DESCRIPTION::
5 Years Warranty IP67 PHILIPS/CREE LED High Bay Light fixture / LED high bay with CE/(EMC,LVD, RoHS), TUV, UL, DLC, FCC, SAAPRODUCT FEATURES:
+ Innovative design accommodates up to 8 LED modules
+ Heat-sinking technology ensures long lifespan and low light decline
+ Double coupling design guarantees IP67 protection for wet locations
+ Valid over the entire temperature range from -40 ºC to +50 ºC ( -40 ºF to 122 ºF )
+ Heavy Duty Anodized Die-cast aluminum housing and corrosion resistant dacromet coating
+ System rating is 50,000 hours @ L80 (80% lumen maintenance) +UL/CUL(Wet Locations)
ADVANTAGES:
1. Using Netherland original Philips-Lumileds LUXEON® T LEDs
2. High quality MEANWELL UL listed power supply
3. Luminous flux efficient >105lm/w
4. Variety of beam angle: 60°/90°/120° (8°/25° /40° optional
5. Lifespan > 50000H
6. 5 years warranty
7. CE(EMC, LVD, ROHS), TUV, UL, DLC, FCC, SAA listed
APPLICATIONS:
+ Industrial Halls and Warehouses
+ Manufacturing Plant
+ Cold Storage
+ Exhibition Halls
+ Distribution Center
+Big-Box Retail Stores
TECHNICAL PARAMETERS FOR MODEL NJZ-FLB-50
| Model | NJZ-FLB-50 |
| Power | 50w |
| Color Temperature | 3000K/4000K5700K |
| Module Usage | LED18*1Module |
| LED Chip | Philips-Lumileds |
| Driver | Meanwell |
| Light Efficiency | ≥105lm/w |
| CRI | Ra≥70 |
| Input Voltage | 100-277VAC |
| Beam Angle | 60°/120° |
| IP Rating | IP67 |
| Housing Material | Aluminum Alloy |
| Lens Material | PC |
| Dimension (L-W-H) | 14.0*7.1*6.1in |
| Net Weight | 3.1kg / 6.81bs. |
TECHNICAL PARAMETER FOR ALL MODELS
| Model | NJZ-FLB-PI |
| LED Chip Brand | Philips-Lumileds LUXEON® T |
| Driver Brand | Inventronics / Meanwell |
| Norminal Wattage | 40W~400W |
| LED Module Usage | 1~8 Units |
| Input Voltage | AC100V-277V(50/60Hz) and 347-480 volt optional |
| Power Supply Efficiency | ≥91% |
| Power Factor | >0.95 |
| Luminous Efficacy | >105Lm/W |
| Luminous Flux (Lumen Output) | 4000Lm~40000Lm ( Tolerance +/- 5% ) |
| Color Rendering Index | Ra>75 |
| Color Temperature | 3000k / 4000k / 5700k |
| Light Distribution | Using secondary optical lens for light distribution |
| Beam Angle | 60°/90°/120° (8°/25° /40° optional ) |
| Work Condition | Operation Temperature: -40ºC ~ +50ºC Humidity: 10%~90% RH |
| Optimal Operating Temperature | 25ºC |
| Housing Material | Anodized Die Cast Aluminum |
| IP Rating | IP67 |
| Protection Level Against Electric Shock | Class I |
| Mounting Method | Ceiling,Pendant,Wall Type |
| Operation Lifespan | > 50000 Life Hours |
| Warranty | 5 years limited system warranty standard |
