  5 Years Warranty Energy Saving 60W LED Solar Power Street Light
                                  with CE Approved



 1. Brief Specification for 8M pole 60W Solar LED Street Lights.

Design based on Africa's average solar radiation condition 5.0KWH,Lighting hours: 11-12 Hrs/Day*3-4 days.

a. Pole Height: 8M, Diameter: 75*180mm, Thickness: 3.75mm
   Plastic coated on HDG pole, resistant to wind: 150KM/H
b. Applicable light source: 60W LED, 7200LM,Lifespan:>80000Hrs.
c. PV Module: High efficient 120W*2PC.
d. Gelled battery: 120Ah*2PC, Fee Maintence, Deep Cycle, Sealed Type.
e.Battery Box: Engineer Plastic, Bury under ground
f. Controller: 15A/24V Automatic control by microcomputer
g. Fittings


2. Detatiled Specificaiton

      Detailed Specification for 8M pole 60W Solar LED Street Light

Part Name and Lifespan

Technical Specification

Solar Panel:

Lifespan:20-25 years

120W*2PCs Polycrystalline. High Efficiency. A-class

Adding Aluminum Frame, Tempered Glass.

Gelled Battery

Lifespan:5-8 years

120Ah/12V*2PCs, Gelled battery, Sealed Type.

Deep cycle. Maintenance Free

Intelligent Solar Controller

Lifespan:5-10 years

15A/24V,IP68. Automatic Light and Time Control

Over-charging/discharging Protection

Reverse-connection Protection

Switch on Automatically with Light Sensor;

Light source: High Power LED

Lifespan: More than 50000-100000Hrs

60W LED, White Color,7200LM/PC,6500K,IP65,

High Power, High Brightness.

Lamp Housing:

Lifespan: More than 20 years

Die-casted Aluminum, IP65

High transmittance & Density toughened glass,

Battery Box:

Engineer plastic,underground of the pole.

GI Pole System:

Lifespan: More than 20 years



8M Height, tapered Pole, Steel,

Hot-Dip Galvanized. Plastic Coated, Rust Proof,

With Arm, Bracket, Flange, Fittings, Cable, Etc

Resistant to Wind: ≥150KM/H







3.Solar LED Street Lights Working Principle:

1Solar LED street light relies on solar energy, which is clean, endless and environment-friendly.
2The system is mainly composed of solar panel, light source, controller and free-maintenance battery.
3In daytime, when there is sunshine, the solar panel can convert the solar energy to electric energy and store it in the battery. At night or rainy or cloud condition, the battery shall supply power for normal lighting.
4The controller can judge the brightness of daylight and automatically switch on the light. The whole process is operating in completely automatic mode, without human action.


4.8M Pole Soalr LED Street Lights Applications

Solar Street LightsSolar Street LightingSolar Street Lighting System
Solar LED LightSolar LED Street LightSolar Garden Light
Solar Freeway LightSolar Campus LightSolar Avenue Light
Solar Pedestrian Street LightSolar Sidewalk LightSolar Gate Light
Solar Path LightSolar Pathing LightSolar Park Light
Solar Parking Lot LightSolar Driving way LightSolar Pedestrian Street Light
Solar Remote Area LightAirport Solar lightSolar Street Lamp

   5.Factory Show


Pls Enter http://jinshangsolar.en.made-in-china.com  for more information about JS SOLAR marked Hot Sale Solar LED Street Light and Solar LED Lights.
Pls send us more details about your purchasing,
Thank you for your time and attention.
Prod Model: JS-A20158060
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Warranty:5years: Height:8m
Light Source: LED Lamp
Lamp Body Material: Aluminum Alloy
Light Type: Energy Saving
Color Temperature: Pure Wihte
Technics: Electroplating
Illumination Time: 8h
Cell Type: Ni-Cd Battery
Charging Time (',H): 6
Usage: Street
IP Rating: IP65
Certification: RoHS
Voltage: 12/24V
With Light Source: With Light Source
Power: 15W-60W
Jinshang Solar Lighting Co., Ltd. is situated in Guoji industrial park of Yangzhou city, a Chinese famous historical city, which nearing the Jinghu high way in east, closing to Huning high way in south, approaching Ruiyang great bridge, with superior location and fast and convenient traffic. This is a large outdoor lighting production enterprise, integrating of design, research and development, manufacture, setting and service.

Now, we have over 300 stuffs, including over 50 technicians. Covering 20, 000 squares meters area, we have large numerical control bending machine, aluminum die-casting machine of 2000ton, hydraulic tensile machine, double powder electrostatic spraying line, automatic cutting machine, arc-submerging welder, gas welding, vehicle, and digging, drilling, bending and over hundred equipments. We have various products, such as die-cast aluminum lamp, cone-shaped, rhombic, variable diameter lamp pole, high pole lamp, combination lamp, garden lamp, high pressure sodium lamp, ballast and parts appliances

We hold the management principle of" strive for survival on the basis of quality, explore the markets on the basis of sincerity". The developing goal is to meet the requirements of our clients and to establish the brand effect of Jinshang. We implement the special technical activities and establish qualified archives in a long time, which is to improve and enhance our manufacturing technique. We also try our best to make our rules and regulations perfect. We will continue to warmly welcomes the communities to come to new and old customers visit our company and guide! The company mainly produces and sells various types of solar street lamp, wind solar hybrid street light, electric power street lamp, PV off-grid equipment, garden lamp, landscape lamp, pole lamp, project lamp, digital LED lights, lawn lamp, underground lamp, lifting pole lamp, cone-shaped and polygonal variable diameter steel pole, electrified rail pole, traffic bar, flagpole, various type of light source appliances, and other parts of ballast, trigger, light or time controller electrical appliances and so on, which widely applied in outside roads, squares, parking lots, wharf, garden etc.

Our company gets rich experiences in city lighting engineering which work in this field over 10 years. We are the enterprise of attaching importance to contract and credit in Jiangsu. We enjoined the reputation of quality reliable enterprise in Jiangsu as well as excellent enterprise of standardized implement. Our company rated AAA grad credit enterprise, and through ISO9001international quality system certification. The enforcement of product certification in nation as well as AAA grad, CCC, CCCC2, ISO14001 Certification of environment protection. We also own the third certification of street lighting engineering contractor. We also get the permission of safe production.

In 2015, Wuhan office Hubei, Jinshang lighting Co., Ltd and Lighting equipment, Yangzhou, Jinshang Co., Ltd. Invest to establish a 5000-square-meter solar PV production line together, which import the most advanced equipment of manufacture and testing in the world to make sure the high quality of solar PV module in the international field. The assembly line of solar PV manufacture the solar street light and Off-grid solar system whose products are popular both at home and abroad, such as Middle East, south America, Africa and so on.
