40W Double Arm Solar LED Street Light
Product Details
1. LED lamp: Super bright LED,5500-6500K for choice, 120LM/W, IP65 cast aluminum lamp housing.
2. solar panel: High efficiency polycrystalline solar pane, with aluminum frame, tempered glass and junction box.
3. battery: Maintenance free gelled valve regulated sealed battery, deep cycle.
4. solar controller: Intelligent solar controller, IP68 waterproof, with protection functions and energy saving modes etc.
5. battery box: IP 65 waterproof battery underground box (battery box on pole top is optional)
6. cable :Cable to meet relevant solar lighting purpose
7. light pole: Optional light pole made of Q235 quality steel, hot dipped galvanized & plastic powder coated, rust proof. With light arm, flange base & anchor bolts, solar panel bracket and screws.
Configuration of 40W Double Arm Solar Street Light
| LED lamp | 40Watts |
| Solar panel | 2*80Wp |
| Storage battery | 12V/2*90AH gel battery |
| Solar controller | 12V/24V auto 10A |
| Battery box | 24V/120AH |
| Applicable light pole | 8~9 meters |
| Lighting time | 10-12 hours |
| Backup days | 3-4 backup overcast or rainy days |
| System voltage | DC24V |
| Design Mode | Full power |
| Warranty | 3 years |
Note: Above configuration is designed on averaged insolation 5.5 kWh/m2/day
Working Principle:
1. LED solar street light relies on solar energy, which is clean, endless and environment-friendly.
2. The system is mainly composed of solar panel, light source, controller and free-maintenance battery.
3. In daytime, when there is sunshine, the solar panel can convert the solar energy to electric energy and store it in the battery. At night or rainy or cloud condition, the battery shall supply power for normal lighting.
4. The controller can judge the brightness of daylight and automatically switch on the light. The whole process is operating in completely automatic mode, without human action.
Applications:
A. Highway
B. City main road
C. School campus road
D. Sidewalk
E. Pathway
F. Farm & ranches lighting
G. Villa lighting
H. Landscape lighting - park, square etc.
In order to design and quote the solar street light exactly, please inform us below information:
1. The installation city
2. LED lamp power
3. Light pole height
4. Lighting hours per nigh
5. Backup rainy days
6. Quantity you need
If you want to know more information, please contact us, we will reply you in the earliest time!
