Home LED Light Products 3W 3000k SMD LED Light / Ceiling Lamp / Down Light

3W 3000k SMD LED Light / Ceiling Lamp / Down Light

3W 3000k SMD LED Light / Ceiling Lamp / Down Light
Price: Negotiable/Piece
Trade Terms: FOB,EXW
Min Order: 200/Piece
Pay Type: L/C,T/T
3W 3000K SMD LED Light / Ceiling Lamp / Down Light Features Of LED Ceiling Lamp : * Imported SMD chip * High luminous efficiency * High heat radiation performance * Anodized surface with anticorrosion, no color-fading. * Straight fin line designwith enlarged cross-ventilationeffect, doubled the heat radiation effect. * Long life electric capacity * Wide voltage design Specification Of LED Ceiling Lamp : Model:                                             YL-DL2C Size:                                                Ø90*H45mm Shell:                                               Premium Lathe Aluminum shell LED Power:                                    Isolated power supply Fixing Hole Size:                            75mm Input Voltage:                                 AC85-265V Power:                                             3W Power Factor:                                 >0.85 Color Temperature:                      3000K ±150 Luminous Flux:                              ≥180 CRI:                                                  >80 Beam Angle:                                  120°-180° Light cover:                                     Polished bulb cover Working Temperature:                 -20~+45ºC Storage Temperature:                  -30~+55ºC Working Life:                                  30000H Gurantee:                                        3 years Certificate:                                      CE, FCC, RoHS Remarks:                                       3W, 4W, 5W available Our life span is 40000h in the environment temperature -20ºC~35ºC and relative humidity <80%. Testing report of warm white 3w led ceiling lamp : Application Of LED Ceiling Lamp : * Widely applied in office building, metro, subway, school, hospital, hotel, supermarket, workshop, advertisement, corridor, home etc.. Certificate:CE(EMC &LVD),FCC,RoHS Yilang services: 1. Your inquiry related to our products or prices will be replied in 24hours. 2. OEM & ODM are welcomed, OEM brand is available. 3. Any defective products within warranty will get maintenance or replacement unconditionally. 4. Protect your sales area Trade Terms: 1. Payment: T/T, L/C at sight available 2. Samples can be available within 5-7 working days;     Order: 15-30Days,according to the accurate order quantity. 3. Shipping freight is quoted under your requests 4. Shipping port:Shanghai, China 5. Discouts are offered based on order quantities 6. MOQ: 200pcs
Model Size
(mm)
Shell Fixing Hole Input Voltage Power PF Color Temp. Luminous Flux CRI Beam Angle
YL-DL2C Ø90*H45 premium Lathe Aluminum 75mm AC85-265V 3W >0.85 3000K ±150 ≥ 180 >80 120°-180°
YL-DL2C Ø90*H45 premium Lathe Aluminum 75mm AC85-265V 3W >0.85 6000K ±200 ≥ 190 >80 120°-180°
YL-DL3C Ø110*H50 premium Lathe Aluminum 95mm AC85-265V 6W >0.95 3000K ±150 ≥ 420 >80 120°-180°
YL-DL3C Ø110*H50 premium Lathe Aluminum 95mm AC85-265V 6W >0.95 6000K ±200 ≥ 450 >80 120°-180°
YL-DL4C Ø140*H55 premium Lathe Aluminum 125mm AC85-265V 12W >0.95 3000K ±150 ≥ 840 >80 120°-180°
YL-DL4C Ø140*H55 premium Lathe Aluminum 125mm AC85-265V 12W >0.95 6000K ±200 ≥ 850 >80 120°-180°
YL-DL5C Ø160*H55 premium Lathe Aluminum 145mm AC85-265V 15W >0.9 3000K ±150 ≥ 1000 >80 120°-180°
YL-DL5C Ø160*H55 premium Lathe Aluminum 145mm AC85-265V 15W >0.9 6000K ±200 ≥ 1050 >80 120°-180°
YL-DL6C Ø185*H65 premium Lathe Aluminum 170mm AC85-265V 18W >0.9 3000K ±150 ≥ 1250 >80 120°-180°
YL-DL6C Ø185*H65 premium Lathe Aluminum 170mm AC85-265V 18W >0.9 6000K ±200 ≥ 1400 >80 120°-180°
Power supply : CE isolated   ,  working life : 30000hrs   ,  Warranty : 3 years  ,  Certificate : CE ROHS FCC

Prod Model: YL-DL2C
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Lamp Beads Type: SMD5730
Lamp Beads Qty: 14PCS
Size: Ø90*H45mm
Luminous Flux: ≥180
Luminous Efficacy: 60lm/W
Beam Angle: 120°-180°
Life Span: 40000h
Light Source: LED
Installation: Embedded
Material: Aluminum
Lamp Installation: Plug Lamp
Application: Commercial Lighting&Household
Shanghai Yilang Lighting Technology Co., Ltd is a professional lighting company, registered capital of RMB 10 million, located in Shanghai Baoshan Economic and Development Zone and integrated with LED R&D, manufacturing and sales.

Yilang has its own independent R&D team with engineers work in light, electric, structure and material fields and formed a research center with Shanghai University for LED Extended Application Research to continuously develop solar energy and LED-integrated applicable products. Yilang is indulging to cooperate with top design and R&D institutions around the world to make the first-class product with advanced technology.

All series of products are designed, developed and manufactured by Yilang, which are applicable for road, construction, workshop, warehouse, office, hotel, underground construction, home and landscape decoration etc...By the change of climate, portable and other special application field, Yilang can provide professional and satisfactory design plan to manufacture various customized products.

Yilang manages to strict manufacturing process which guarantees the compliance of CE, FCC, RoHS certificate for our product and high efficiency after-sales service.

Yilang will abide by our core concept of "Thought to drive the quality" to serve sincerely.

Adhere to environmental friendly, energy saving concept, we are willing to starting the pace for civilization of human and the planet earth with you hand in hand.
