316 Stainless Steel LED Waterproof Fountain Light (12*1W)
Features:
Sole & Patented design
316 Stainless steel body + transparent PC cover
IP68 waterproof rating
Constant driver to make sure LED light working stably, avoid any flashing and noisy
Voltage:AC/DC 12V,
Frequency: 50/60HZ
High quality and brightness LED source: 1W & 3W (RGB 3 in 1)
Single color: White (pure white, warm white, cool white), red, green, blue, yellow, etc.
4 kinds of RGB control mode: DMX 512 control; External control;
WiFi control; Automatic control.
Beam angle: high power 25° / 30° / 45° / 60°;
Life span >30,000 hours
Overcurrent protection
Applications: Swimming pool, park, water-fall, fountain spring, garden.
COLOR: Single color or RGB
(1) Single color: White (pure white, warm white, cool white), Red, Green, Blue, Yellow.
(2) RGB:14 kinds of RGB color Change patterns
1. Red (solid color red)
2. Green (solid color green)
3. Blue (solid color blue)
4. Red + green
5. Green + blue
6. Red + blue
7. Red + green + blue = white
8. Dynamic change: red change to green
9. Dynamic change: green change to blue
10. Dynamic change: red change to blue
11. Dynamic RGB change
Dynamic color change: from Red to Green, then Blue
12. Dynamic & Colorful change
Dynamic color change: from Red to Green, then Blue, Red+ blue, Green+ blue, Blue+ red, RGB
13. RGB fading effect
Fading from Red to Green, then Blue
14. Colorful fading effect
RGB control method: 4 Kinds of RGB color Change control methods. Remote control RGB controller, WiFi control, DMX control, External Control, Auto control
Caution :
1. Please read product manual carefully and make sure the working circumstance is compliant with the condition requests in the manual before use the lamps.
2. Make sure that power is cut off before connect the lamps to power supply systems.
3. The lamp should be used under water.
4. Don't mix-connect the 4 wires (V+, B, G, R ) to connect port of LED RGB wire controller (+, B, G, R), otherwise will short-circuit the lamp.
Specification
Parameter
Model No.
PT-FTN-12x1W
LED Qty.
12 pcs 1W (High Power)
Input Voltage
12V AC / DC
Input Frequency
50/60 Hz
Output current
1.8 A
Power
12±1w
Luminous flux
pure white: 880±10%lm
warm white: 850±10%lm
cool white: 820±10%lm
R: 260lm G: 520lm B: 100lm
RGB: 350±10%lm
Working
temperature
-10-50ºC
Color
temperature
p.w.6000~7000k
w.w.:3000-3500k
c.w.8000~10000k
Wave length
R:620-630 K/nm
G:515-525 K/nm
B:460-470 K/nm
Dimension
179×77 mm
Constant driver
yes
IP rate
IP68
overcurrent protection
yes
