2015 new 18x3W Led Swimming Pool Underwater Light ,IP68 pool light,low voltage 12V spec:
Specification | Parameters |
Model No. | LF-SPL-18*3W-F1 (RGB 3IN1) |
LED Qty | 18 pcs 3W(RGB 3 IN 1)High Power |
Input Voltage | AC/DC 12-13V |
Frequency | 50/60 Hz |
Power | 25±1.5w(RGB) |
Color Temperature | RGB only |
Luminous Flux | 880±10%Lm (RGB) |
Color Rendering Index(CRI) | RGB only |
Wave Length | R/G/B:620-630/515-525/ 460-470 nm |
Beam angle | 30°/45°/60° |
Dimension | 290*66mm |
Working temperature | 0~40ºC |
Storage Temperature | 0~50 ºC |
Constant driver | yes |
IP rating | IP68 |
2015 new 18x3W Led Swimming Pool Underwater Light ,IP68 pool light,low voltage Features:
1.IP68 Structure water proof ( private tooling & patented product), unique internal design, good at waterproof and anti-corrosion.
2.RGB synchronization with patented RGB controller
3.Size:
1) 290(diameter) * 66(height) mm
LF-SPL-18X3W-F1-(RGB 3 IN 1)/LF-SPL-18X1W-F1/LF-SPL-105S5-F1
LF-SPL-252D5-F1/LF-SPL-315D5-F1/ LF-SPL-20X1W-F1(SMD5730)
2) 250(diameter) * 47(height) mm
LF-SPL-12W (SMD5730)-F1 / LF-SPL-12W (SMD5050)-F1
HG-P56M-12W (SMD5730)-T1 / HG-P56M-12W (SMD5050)-T1
4.Thermal plastic body & pc cover, easy to install and excellent performance on heat dissipation.
5.Constant driver to make sure LED light working stably, avoid any flashing and noisy
6.Voltage:AC/DC 12V, Frequency: 50/60HZ
7.Color: Single color - white, red, green, blue, yellow
8.Color: RGB, 14 kinds of color changing
9.6 kinds of RGB control mode: Remote control, WIFI control, DMX 512 control,
External control, Remote & switch remote control, Automatic control
10.Beam angle:SMD5050/3528/5730-120°, high power-25°or 30°or 45°or 60°
2015 new 18x3W Led Swimming Pool Underwater Light ,IP68 pool light,low voltage
Dimension: 290mm * 66mm or 250mm *47mm
2015 new 18x3W Led Swimming Pool Underwater Light ,IP68 pool light,low voltage Installation Diagram
2015 new 18x3W Led Swimming Pool Underwater Light ,IP68 pool light,low voltage application:
