18*12W RGBWA UV 6in1 Zoom Waterproof Outdoor LED PAR
Price: |
US $ 150-250/Piece |
Trade Terms: |
FOB,CFR,CIF |
Min Order: |
1/Piece |
Pay Type: |
L/C,T/T,Western Union |
18pcs 12w RGBWA UV 6in1 Zoom waterproof outdoor LED PAREmitting Color6 Color Wash effectTechnical Parameter Tech Spec |
Input voltage | AC100V-220V, 50/60HZ; |
Rated power | 240W; |
Light source | 18pcs 12W RGBWAUV 6in1 led chips; |
LED luminance: More than 5,000 lux; |
Average life: 80000~100000 hours; |
LED Lamp powr supply | Adopt power factor correction PFC switching power supply, PF> 0.99, the efficiency of up to 90%, it's real green and environmental protection; |
LED drive mode | Adopt static constant current drive mode with high precision and non-flicker (400HZ); |
Color system | Purple (Ultraviolet), Amber, Red, Green, Blue, White 6in1 Color mixing system with color rainbow which is reaching high colour rendering index |
Color effect | Uniform color washing effect with no colour shadows, rich saturated and more pastel lighting; |
Zoom | Linear zooming; |
Lens | 18pcs high efficiency and transmission large lens; |
Emitting angle | 10°~60°; |
Waterproof grade | IP64; |
Strobe | 1~10 strobes/seconds; |
Dimmer | 0~100% linear dimmer; |
Control mode | DMX512 signal 3-pins connection control, master-salve control, multiple connection in series control with self-programming mode, self-running mode, external control mode; |
Channel | 11 Channel; |
Other function | DMX address can be adjusted; DMX address extension function; IP address extension function; |
Working temperature | -15° C ~45° C; |
Shell material | Aluminum alloy; |
Application | TV studio, theater, opera house, auditorium, stage, T-stage, concerts, and vocal concert, DJ effect, disco effect, club effect, party effect etc; |
Packing size | 300×300×380mm; |
Gross weight | 10Kg; |
10 channles | Function |
CH 1 | Dimming |
CH 2 | RED |
CH 3 | GREEN |
CH 4 | BLUE |
CH 5 | WHITE |
CH 6 | ULTRAVIOLET |
CH 7 | AMBER |
CH 8 | Strobe |
CH 9 | Speed |
CH 10 | Auto Running & Sound Control |
CH 11 | Zoom |
Production Line
Prod Model: |
UP-PF1812 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Display: |
LED Display |
Channel: |
11CH |
Power Supply: |
Meanwell Taiwan |
Color: |
RGBWA UV |
Zoom: |
10-60degree |
LED: |
12W |
LED Qty: |
36PCS |
Power: |
12W |
Waterproof: |
Waterproof |
IP Rating: |
IP66 |
Life: |
80000h |
Electric Current Type: |
AC |
Shell Material: |
Aluminium Alloy |
LED Chips: |
CREE |
Certification: |
RoHS |
Type: |
PAR18 |
Emitting Color: |
RGBWA+UV |
Input Voltage: |
AC100V-220V, 50/60Hz |
Uplight Stage Equipment (Guangzhou) Co., Ltd. is a high-tech company, which is engaged in R&D, manufacturing and marketing of stage equipments. The main products include moving lighting, LED stage equipments, follow spot, laser light, gobo light, etc.
We own a professional R&D team, who has 10 years experience in stage lighting. Our sales team can provide best service by engineers and technical staff members' supporting. We passed the ISO9001: 2000 quality management system standard as well. There are numerous domestic projects we have been undertaken, was praised by all the customers.
To become the leading stage lighting supplier on a global basis. We view our customers as the most important element in our business, strive to exceed the customer's expectation.
