Home LED Light Products 10W CREE DC10-30V Waterproof IP68 LED Motorcycle Driving Light

10W CREE DC10-30V Waterproof IP68 LED Motorcycle Driving Light

10W CREE DC10-30V Waterproof IP68 LED Motorcycle Driving Light
Price: US $ 10-20/Piece
Trade Terms: EXW
Min Order: 10/Piece
Pay Type: T/T,Western Union,Paypal
Why choose us:

1. FIT MENT:
Universal motorcycle, such as Harley, Honda, YAMAHA, Suzuki, Kawasaki, Buell Lightning, BMW, triumph, Ducati Motor, Aprilia, Cagiva.

2. YTW10 SLOGAN:
" WORLD-CLASS QUALITY, HALF COMPETITOR'S PRICE "

3. FEATURES:
1). Latest Product & Original Design: The YTW10 is designed as a Most Efficient Super-Mini LED Off- Road Light.
2). Wide Input Voltage: DC10~30V, which is suitable for different types of vehicles.
3). CREE High Performance LED chip: Ensure the long lifespan and superior illumination & stability.
4). High Luminous Efficiency: Output over 950 Lumen High Brightness Light, equivalent to 110W Halogen Light!
5). Materials: Pure Aluminum Housing + Virtually Unbreakable PMMA Lens + Stainless Steel Mounting Bracket with IP68 Rate, while the Aluminum face plate acts as radiant heat sink and can melts snow and ice.
6). Environmental-Friendly: Energy saving, no UV and IR radiation, Shock-Proof and Anti-Corrosion.

3. APPLICATIONS:
YTW10 LED Working Lights are widely applied in Motorcycles, Dirt bikes, ATVs, UTVs, Off-road Vehicles, Excavators, Trucks, Mining, Tunneling & Caving Equipments, Road Construction, Outdoor Emergency Lighting, Ambulance & Fire Engine, Trains and Tanks etc.

4. PACKING:
Pearl protect packing inside and carton packing at outside.

LIVE SHOW:






SPECIFICATION
Technical parameters
Model NO. YTW10
Input voltage DC10~30V
Constant Current 900mA 12V,400mA 24V
Power consumption 10W
Luminous Flux 950~1080lm
LED Source Cree High Brightness LED Chip
Certification CE, RoHS & FCC
Optional Color Black,Silver,red,golden
Canning Materials Aluminum Alloy
Lens Virtually Unbreakable PMMA Lens, Light Transmittance>93%, Heat Resistance>90°C.
Support & Connector Stainless Steel mounting bracket with Deutsch socket connector
CCT 6,000~7,000K
Optional Light Type Flood Beam(45deg) / Spot Beam(25deg)
IP rate IP68
Dimension ( mm ) 51.2(D)* 61.0(W)* 66.7(H)
Working temperature -45~105centi-degree
Working humidity 10%~98%
Light source life span >50,000Hrs
Electrostatic Discharge Threshold (HBM) CLASS 2
Warranty 1 year in Normal Use

Prod Model: YTW10S
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Constant Current: 900mA 12V, 400mA 24V
Power Consumption: 10W
Luminous Flux: 950~1080lm
Lens: PMMA, Light Transmittance>93%
Waterproof Rate: IP68
Light Angles: Flood Beam/Spot Beam
Dimension(Mm): 51.2(D)* 61.0(W)* 66.7(H)
Cct: 6.000~7000k
Working Temperature: -45~105centi-Degree
Reverse Voltage: Protected
Material: LED
Resistance: Waterproof
