Key features
·RGB SMD 3-in-1 LEDs
·High brightness, able to work in bright environment
·Aluminum alloy cabinet,
·Ultra-thin, 60mm thickness,
·Super light weight, 6Kg,
·Fresh and uniform color, clear and vivid image
·Low power consumption and high energy-saving
·Simple wiring, fast installation
·Durable, high reliability & stability
Application
Billboard, stadium, airport, shopping mall, etc
| Technical specifications |
|
|
| Model | F-I-P1.563 | F-I-P1.923 | F-I-P2.5 |
| Product name | Indoor full color LED display |
| LED wave length | R: 620-625nm, G: 520-525nm, B: 465-470nm |
| Pixel |
|
|
|
| Pixel pitch | 1.563mm | 1.923mm | 2.5mm |
| Pixel configuration | 1R1G1B | 1R1G1B | 1R1G1B |
| LED Encapsulation | SMD1010 | SMD1010 | SMD2121 |
| Module |
|
|
|
| Resolution of module | 128*96=12,288 Dots | 104*78=8,112 Dots | 64*32=2048Dots |
| Size of module | 200*150 | 200*150 | 160*80 |
| Cabinet |
|
|
|
| Resolution of cabinet | 384*384= | 312*312 | 192*192 |
| Size of standard cabinet | 600(L) x 600(H) mm | 600(L) x 600(H) mm | 480(L) x 480(H) mm |
| Cabinet material | Aluminum alloy |
| Thickness of cabinet | 60mm |
| Weight of cabinet | 8 kg | 8 kg | 6 kg |
| Panel |
|
|
|
| Pixel density | 409,600dots/m² | 270,400 dots/m² | 160,000 dots/m² |
| Brightness | ≥1200CD / m² | ≥1200CD / m² | ≥1500CD / m² |
| Grey scale | 12 bits/4096 levels | 12 bits/4096 levels | 12 bits/4096 levels |
| Colors | 68.7 Billion | 68.7 Billion | 68.7 Billion |
| View angle | H:150°; V:120° | H:150°; V:120° | H:150°; V:120° |
| Optimal view distance | 2-20M | 2-20M | 2-20M |
| Average power consumption/sqm | 500 Watts | 500 Watts | 500 Watts |
| Max. power consumption | 1200 Watts /m2 | 1200 Watts /m2 | 1200 Watts /m2 |
| Refresh rate | ≥1200HZ | ≥1200HZ | ≥1200HZ |
| IP rating |
IP31 Waterproof & dustproof ( front and back ) |
| Control |
|
|
|
Driving mode | Constant current driving |
| 1/32 scan | 1/26 scan | 1/16 scan |
| Signal Interface | Ethernet (network) interface |
| Support input source | RF,RGB,RGBHV, HDTV, SDI, HD-SDI, S-video, composite,DVI,etc |
| Control mode | Synchronous display with control PC by DVI |
| Control distance | Cat5 Ethernet cable ≤120m ; Optical fiber : 10000m |
| Operation |
|
|
|
| Power supply | 110V/220 V AC , 50HZ/60 Hz |
| MTBF | ≥5,000 hours | ≥5,000 hours | ≥5,000 hours |
| Lifespan | 75,000 ~100,000 hours | 75,000 ~100,000 hours | 75,000 ~100,000 hours |
| Out of control rate | <0.0001 | <0.0001 | <0.0001 |
| Operation temperature | Minus 20ºC~60ºC | Minus 20ºC~60ºC | Minus 20ºC~60ºC |
| Operation humidity | 10%~95%RH | 10%~95%RH | 10%~95%RH |
| Storage & Application |
|
|
|
| Storage temperature | Minus 40ºC~85ºC | Minus 40ºC~85ºC | Minus 40ºC~85ºC |
| Storage humidity | 30%~60%RH | 30%~60%RH | 30%~60%RH |
| Application | For indoor use , for rental |
